TA3FLB Series
Manufacturer: SWITCHCRAFT/CONXALL
Beta
⌘K
TINI-QG "MINI XLR" 3 PIN FEMALE CABLE MOUNT, NO FLEX RELIEF (LARGE CABLE OPENING), SILVER PINS, BLACK
| Part | Shell Size - Insert | Cable Opening [Min] | Cable Opening [Max] | Cable Opening [Max] | Cable Opening [Min] | Features | Current Rating (Amps) | Shielding | Shell Finish | Mounting Type | Contact Finish - Mating | Contact Material | Orientation | Backshell Material, Plating | Color | Voltage Rating | Insert Material | Fastening Type | Operating Temperature [Min] | Operating Temperature [Max] | Shell Material | Connector Type | Termination | Applications | Primary Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SWITCHCRAFT/CONXALL | Mini XLR | 0.115 " | 0.19 " | 4.83 mm | 2.92 mm | Backshell Cable Clamp | 5 A | Shielded | Chrome | Free Hanging (In-Line) | Silver | Copper Alloy | Keyed | Thermoplastic | Black | 125 VAC | Thermoplastic | Latch Lock | -55 C | 85 °C | Copper Alloy | Plug Female Sockets | Solder | Audio | Metal |
