7616 Series

Catalog

3M STANDARD SOCKET / HEADER MIL

Part	Insulation Color	Termination	Connector Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Shrouding	Number of Positions Loaded	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Finish - Post	Fastening Type	Pitch - Mating	Pitch - Mating	Contact Length - Post [custom]	Contact Length - Post	Number of Rows [custom]	Contact Finish - Mating	Mounting Type	Contact Shape	Contact Type	Number of Positions	Contact Finish Thickness - Post	Contact Length - Post [x]	Contact Length - Post [x]
3M Electronic Specialty 7616-6002PL	Gray	Solder	Header	8 µin	0.203 µm	Shrouded - 4 Wall	All	0.1 in	2.54 mm	Gold	Push-Pull	0.1 "	2.54 mm	0.11 in	2.79 mm	2	Gold	Through Hole	Square	Male Pin	16
3M Electronic Specialty 7616-5002 PL	Gray	Solder	Header	8 µin	0.203 µm		All	0.1 in	2.54 mm	Gold		0.1 "	2.54 mm			2	Gold			Male Pin	16	Flash	0.11 in	2.8 mm
