IHLP-5A Series

Catalog

POWER INDUCTOR, 8.2UH, SHIELDED, 8.61A ROHS COMPLIANT: YES

Part	Current Rating	Package / Case	Package Name	Operating Temperature (Max)	Operating Temperature (Min)	Shielding	Mounting Type	Frequency - Self Resonant	Type	Current - Saturation (Isat)	Tolerance	Inductance	Height - Seated (Max)	Size / Dimension Length	Size / Dimension Width	DC Resistance (DCR) (Max)	Ratings	Inductance Frequency - Test	Material - Core
Vishay Dale IHLP4040EDER8R2M5A	8.61 A	Nonstandard	4040	155 °C	-55 °C	Shielded	Surface Mount	12.55 MHz	Molded	11.1 A	20 %	8.2 µH	0.213 in	0.453 in	0.406 in	22.36 mOhm	AEC-Q200	100 kHz
Vishay Dale IHLP3232DZERR47M5A	27 A	Nonstandard		125 °C	-55 °C	Shielded	Surface Mount	77 MHz	Molded	19 A	20 %	470 nH	0.157 in	0.322 in	0.322 in	2.55 mOhm	AEC-Q200	100 kHz
Vishay Dale IHLP3232DZERR22M5A	36 A	Nonstandard		125 °C	-55 °C	Shielded	Surface Mount	117 MHz	Molded	32 A	20 %	220 nH	0.157 in	0.322 in	0.322 in	1.86 mOhm	AEC-Q200	100 kHz
Vishay Dale IHLP5050EZER1R8M5A	28.62 A	Nonstandard		155 °C	-55 °C	Shielded	Surface Mount	26.4 MHz	Molded	26.4 A	20 %	1.8 µH	0.197 in	0.53 in	0.508 in	3.58 mOhm	AEC-Q200	100 kHz
Vishay Dale IHLP4040EDER220M5A	5.53 A	Nonstandard	4040	155 °C	-55 °C	Shielded	Surface Mount	7.23 MHz	Molded	4.99 A	20 %	22 µH	0.213 in	0.453 in	0.406 in	49.22 mOhm	AEC-Q200	100 kHz
Vishay Dale IHLP7575GZER1R0M5A	55 A	Nonstandard		155 °C	-55 °C	Shielded	Surface Mount	31.5 MHz	Molded	81 A	20 %	1 µH	0.276 in	0.752 in	0.75 in	1.34 mOhm	AEC-Q200	100 kHz
Vishay Dale IHLP2525CZER1R5M5A		Nonstandard		125 °C	-55 °C	Shielded	Surface Mount		Molded		20 %	1.5 µH	0.118 in	0.27 in	0.255 in		AEC-Q200	100 kHz
Vishay Dale IHLP3232DZER1R0M5A	19 A	Nonstandard		125 °C	-55 °C	Shielded	Surface Mount	45 MHz	Molded	16.2 A	20 %	1 µH	0.157 in	0.322 in	0.322 in	4.9 mOhm	AEC-Q200	100 kHz
Vishay Dale IHLP2525CZERR68M5A	16.5 A	Nonstandard		125 °C	-55 °C	Shielded	Surface Mount	56.1 MHz	Molded	17 A	20 %	680 nH	0.118 in	0.27 in	0.255 in	5.76 mOhm	AEC-Q200	100 kHz
Vishay Dale IHLP8787MZER2R2M5A	58 A	Nonstandard		155 °C	-55 °C	Shielded	Surface Mount	17.5 MHz		48 A	20 %	2.2 µH	0.512 in	0.885 in	0.866 in	1.25 mOhm	AEC-Q200	100 kHz	Metal Composite
