IR2133 Series

Manufacturer: INFINEON

Catalog

IC GATE DRVR HALF-BRIDGE 28DIP

Part	Current - Peak Output (Source, Sink) [custom]	Current - Peak Output (Source, Sink) [custom]	Voltage - Supply [Max]	Voltage - Supply [Min]	Logic Voltage - VIL, VIH	High Side Voltage - Max (Bootstrap) [Max]	Channel Type	Mounting Type	Package / Case	Package / Case	Package / Case	Supplier Device Package	Driven Configuration	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Number of Drivers	Gate Type	Input Type	Operating Temperature	Package / Case [custom]	Package / Case [custom]	Supplier Device Package	Supplier Device Package [x]	Supplier Device Package [y]
INFINEON IR2133PBF	250 mA	500 mA	20 V	10 VDC	0.8 V 2.2 V	600 V	3-Phase	Through Hole	28-DIP	15.24 mm	0.6 in	28-DIP	Half-Bridge	90 ns	40 ns	6	IGBT MOSFET (N-Channel)	Inverting	125 ¯C
INFINEON IR2133SPBF	250 mA	500 mA	20 V	10 VDC	0.8 V 2.2 V	600 V	3-Phase	Surface Mount	28-SOIC			28-SOIC	Half-Bridge	90 ns	40 ns	6	IGBT MOSFET (N-Channel) N-Channel MOSFET	Inverting	125 ¯C	0.295 "	7.5 mm
INFINEON IR2133PBF	250 mA	500 mA	20 V	10 VDC	0.8 V 2.2 V	600 V	3-Phase	Through Hole	28-DIP	15.24 mm	0.6 in	28-PDIP	Half-Bridge	90 ns	40 ns	6	IGBT MOSFET (N-Channel) N-Channel MOSFET	Inverting	125 ¯C
INFINEON IR2133STR	250 mA	500 mA	20 V	10 VDC	0.8 V 2.2 V	600 V	3-Phase	Surface Mount	28-SOIC			28-SOIC	Half-Bridge	90 ns	40 ns	6	IGBT MOSFET (N-Channel) N-Channel MOSFET	Inverting	125 ¯C	0.295 "	7.5 mm
INFINEON IR2133JPBF	250 mA	500 mA	20 V	10 VDC	0.8 V 2.2 V	600 V	3-Phase	Surface Mount	44-LCC (J-Lead) 32 Leads			44-PLCC	Half-Bridge	90 ns	40 ns	6	IGBT MOSFET (N-Channel) N-Channel MOSFET	Inverting	125 ¯C			32	16.58	16.58
INFINEON IR2133STRPBF	250 mA	500 mA	20 V	10 VDC	0.8 V 2.2 V	600 V	3-Phase	Surface Mount	28-SOIC			28-SOIC	Half-Bridge	90 ns	40 ns	6	IGBT MOSFET (N-Channel) N-Channel MOSFET	Inverting	125 ¯C	0.295 "	7.5 mm
INFINEON IR2133JTRPBF	250 mA	500 mA	20 V	10 VDC	0.8 V 2.2 V	600 V	3-Phase	Surface Mount	44-LCC (J-Lead) 32 Leads			44-PLCC	Half-Bridge	90 ns	40 ns	6	IGBT MOSFET (N-Channel) N-Channel MOSFET	Inverting	125 ¯C			32	16.58	16.58
INFINEON IR2133JTR	250 mA	500 mA	20 V	10 VDC	0.8 V 2.2 V	600 V	3-Phase	Surface Mount	44-LCC (J-Lead) 32 Leads			44-PLCC	Half-Bridge	90 ns	40 ns	6	IGBT MOSFET (N-Channel) N-Channel MOSFET	Inverting	125 ¯C			32	16.58	16.58
INFINEON IR2133	250 mA	500 mA	20 V	10 VDC	0.8 V 2.2 V	600 V	3-Phase	Through Hole	28-DIP	15.24 mm	0.6 in	28-PDIP	Half-Bridge	90 ns	40 ns	6	IGBT MOSFET (N-Channel) N-Channel MOSFET	Inverting	125 ¯C
INFINEON IR2133J	250 mA	500 mA	20 V	10 VDC	0.8 V 2.2 V	600 V	3-Phase	Surface Mount	44-LCC (J-Lead) 32 Leads			44-PLCC	Half-Bridge	90 ns	40 ns	6	IGBT MOSFET (N-Channel) N-Channel MOSFET	Inverting	125 ¯C			32	16.58	16.58
