AET00CC Series
Isolated DC/DC Converters - Through Hole 20W 15V@0.665A 18-75Vin
Manufacturer: ARTESYN / Advanced Energy
Catalog
Isolated DC/DC Converters - Through Hole 20W 15V@0.665A 18-75Vin
Beta
⌘K
Isolated DC/DC Converters - Through Hole 20W 15V@0.665A 18-75Vin
Isolated DC/DC Converters - Through Hole 20W 15V@0.665A 18-75Vin
Isolated DC/DC Converters - Through Hole 20W 15V@0.665A 18-75Vin
| Part | Features | Voltage - Input (Max) [Max] | Mounting Type | Efficiency | Power (Watts) | Voltage - Output 2 | Voltage - Isolation | Current - Output (Max) | Current - Output (Max) | Number of Outputs | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Package / Case | Voltage - Output 1 | Type | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input (Min) [Min] | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ARTESYN / Advanced Energy | OVP Remote On/Off SCP | 75 V | Through Hole | 85 % | 20 W | -15 V | 1.5 kV | 665 mA | 665 mA | 2 | 50.8 mm | 1.6 in | 12.2 mm | 2 in | 0.48 " | 40.6 mm | 7-DIP Module | 15 V | Isolated Module | 71 °C | -40 C | 18 V | ITE (Commercial) |
 ARTESYN / Advanced Energy | OVP Remote On/Off SCP | 36 V | Through Hole | 85 % | 20 W | -15 V | 1.5 kV | 665 mA | 665 mA | 2 | 50.8 mm | 1.6 in | 12.2 mm | 2 in | 0.48 " | 40.6 mm | 7-DIP Module | 15 V | Isolated Module | 71 °C | -40 C | 9 V | ITE (Commercial) |
