har-flexicon FSV Series

Manufacturer: HARTING

Catalog

PLUGGABLE TERMINAL BLOCK, 3.5 MM, 8 POSITIONS, 30 AWG, 14 AWG, 1.5 MM², SCREW

Part	Insulation Height	Insulation Height	Housing Material	Screw Size	Material Flammability Rating	Contact Material	Torque - Screw [Max]	Torque - Screw [Max]	Torque - Screw [Min]	Torque - Screw [Min]	Wire Strip Length [Min]	Wire Strip Length [Max]	Type	Voltage - UL	Mounting Type	Termination Style	Positions Per Level	Number of Levels	Pitch	Pitch	Wire Gauge or Range - mm² [Max]	Wire Gauge or Range - mm² [Min]	Current - UL	Color	Plug Wire Entry	Contact Mating Finish	Operating Temperature [Min]	Operating Temperature [Max]	Wire Gauge or Range - AWG [Min]	Wire Gauge or Range - AWG [Max]	Number of Positions
HARTING 14310814401000	19.2 mm	0.756 in	Nylon Polyamide (PA) Polyphthalamide (PPA)	M2	UL94 V-0	Copper Alloy	2.2 Lb-In	0.25 Nm	0.2 Nm	1.7 Lb-In	5 mm	6 mm	Plug Female Sockets	300 V	Free Hanging (In-Line)	Screw	8	1	3.5 mm	0.138 "	1.5 mm²	0.05 mm²	10 A	Green	90 °	Tin	-40 C	110 °C	14 AWG	30 AWG	8
HARTING 14310614401000	19.2 mm	0.756 in	Nylon Polyamide (PA) Polyphthalamide (PPA)	M2	UL94 V-0	Copper Alloy	2.2 Lb-In	0.25 Nm	0.2 Nm	1.7 Lb-In	5 mm	6 mm	Plug Female Sockets	300 V	Free Hanging (In-Line)	Screw	6	1	3.5 mm	0.138 "	1.5 mm²	0.05 mm²	10 A	Green	90 °	Tin	-40 C	110 °C	14 AWG	30 AWG	6
