15DYS818 Series

Catalog

ADAPTER, AC-DC, 1 O/P, 15V, 1.2A ROHS COMPLIANT: YES

Part	Voltage - Output	Input Type	Form	Applications	Input Connector	Current - Output (Max) [Max]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Approval Agency	Output Connector	Output Connector [diameter]	Output Connector [z]	Power (Watts)	Voltage - Input [Min]	Voltage - Input [Max]	Operating Temperature [Max]	Standard Number	Efficiency	Region Utilized
IDEAL POWER 15DYS818-150120W-3	15 VDC	Fixed Blade	Wall Mount (Class I)	ITE (Commercial)	BS 1363	1.2 A	1.37 in	34.8 mm	66 mm	2.6 in	49.3 mm	1.94 "	CE	Barrel Plug	2.1 mm 5.5 mm	12 mm	18 W	90 VAC	264 VAC	45 °C	62368-1	Level VI	United Kingdom
IDEAL POWER 15DYS818-150120W-2	15 VDC	Fixed Blade	Wall Mount (Class II)	ITE (Commercial)	CEE 7/16	1.2 A	1.1 in	28 mm	67.5 mm	2.66 in	45.5 mm	1.79 "	CE TUV	Barrel Plug	2.1 mm 5.5 mm	12 mm	18 W	90 VAC	264 VAC	45 °C	62368-1	Level VI	Europe
IDEAL POWER 15DYS818-090200W-1	9 V	Fixed Blade	Wall Mount (Class II)	ITE (Commercial)	NEMA 1-15P	2 A	1.1 in	28 mm	67.5 mm	2.66 in	45.5 mm	1.79 "	cULus	Barrel Plug	2.1 mm 5.5 mm	12 mm	18 W	90 VAC	264 VAC	45 °C	62368-1	Level VI	North America
IDEAL POWER 15DYS818-090200W-3	9 V	Fixed Blade	Wall Mount (Class I)	ITE (Commercial)	BS 1363	2 A	1.37 in	34.8 mm	66 mm	2.6 in	49.3 mm	1.94 "	CE	Barrel Plug	2.1 mm 5.5 mm	12 mm	18 W	90 VAC	264 VAC	45 °C	62368-1	Level VI	United Kingdom
