678D Series

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - RADIAL LEADED 330UF 63VOLTS 20% 16X32MM

Part	Tolerance	Height - Seated (Max)	Polarization	Size / Dimension Diameter	Applications	Package / Case	Voltage - Rated	Lifetime	Operating Temperature (Min)	Operating Temperature (Max)	Mounting Type	Capacitance	Lead Spacing	Ripple Current	ESR (Equivalent Series Resistance)	Impedance
Vishay Dale 678D337M063EN4D	20 %	1.319 in	Polar	0.63 in	General Purpose	Can Radial	63 V	4000 Hrs	-55 °C	105 °C	Through Hole	330 µF	0.295 in
Vishay Dale 678D107M063DG3DE3	20 %	0.906 in	Polar	0.492 in	General Purpose	Can Radial	63 V		-55 °C	105 °C	Through Hole	100 µF	0.197 in	504 mA 720 mA	450 mOhm	90 mOhms
Vishay Dale 678D337M040DM4D	20 %	1.102 in	Polar	0.492 in	General Purpose	Can Radial	40 V		-55 °C	105 °C	Through Hole	330 µF	0.197 in	651 mA 930 mA	200 mOhm	70 mOhms
Vishay Dale 678D227M063DT4D	20 %	1.346 in	Polar	0.492 in	General Purpose	Can Radial	63 V		-55 °C	105 °C	Through Hole	220 µF	0.197 in	1.1 A 770 mA	160 mOhm	54 mOhms
Vishay Dale 678D108M016EK5D	20 %	1.098 in	Polar	0.63 in	General Purpose	Can Radial	16 V	4000 Hrs	-55 °C	105 °C	Through Hole	1000 µF	0.295 in
Vishay Dale 678D108M025DS3D	20 %	1.791 in	Polar	0.492 in	General Purpose	Can Radial	25 VAC		-55 °C	105 °C	Through Hole	1000 µF	0.197 in	1.12 A 1.6 A	90 mOhm	36 mOhms
Vishay Dale 678D337M016CD3D	20 %	0.74 in	Polar	0.394 in	General Purpose	Can Radial	16 V	3000 Hrs	-55 °C	105 °C	Through Hole	330 µF	0.197 in	364 mA 520 mA	370 mOhm	136 mOhms
Vishay Dale 678D337M063EN5J	20 %	1.417 in	Polar	0.63 in	General Purpose	Can Radial	63 V	4000 Hrs	-55 °C	105 °C	Through Hole	330 µF	0.295 in
Vishay Dale 678D507H016DG5J		0.906 in	Polar	0.492 in	General Purpose	Can Radial	16 V		-55 °C	105 °C	Through Hole	500 µF	0.197 in
Vishay Dale 678D338M010EN5O	20 %	1.417 in	Polar	0.63 in	General Purpose	Can Radial	10 V	4000 Hrs	-55 °C	105 °C	Through Hole	3300 µF	0.295 in	1.092 A 1.56 A	85 mOhm	41 mOhms
