DC400D Series

Catalog

SSR RELAY SPST-NO 10A 1-300V

Part	Approval Agency	Package / Case	On-State Resistance (Max) [Max]	Voltage - Input [Max]	Voltage - Input [Min]	Output Type	Mounting Type	Load Current	Termination Style	Voltage - Load [Max]	Voltage - Load [Min]	Operating Temperature [Min]	Operating Temperature [Max]
Sensata-Crydom DC400D10	CE cURus	Hockey Puck	155 mOhms	32 VDC	4 V	DC	Chassis Mount	10 A	Screw Terminal	300 V	1 V	-40 C	100 °C
Sensata-Crydom DC400D10C	CE cURus	Hockey Puck	155 mOhms	32 VDC	4 V	DC	Chassis Mount	10 A	Screw Terminal	300 V	1 V	-40 C	100 °C
Sensata-Crydom DC400D20C	CE cURus	Hockey Puck	110 mOhms	32 VDC	4 V	DC	Chassis Mount	20 A	Screw Terminal	300 V	1 V	-40 C	100 °C
