81044/12 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

HOOK-UP STRND 12AWG 600V WHITE

Part	Conductor Material	Wire Gauge	Cable Type	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket Color	Voltage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Jacket (Insulation) Material	Grade	Qualification	Spool Size [x]	Spool Size [x]	Length
TE Connectivity AMP Connectors 81044/12-12-9-L106	Copper Tinned	12 AWG	Hook-Up	37	28 AWG	0.0031 in	0.08 mm	White	600 V	0.108 in	2.74 mm	150 °C	-65 ░C	Polyvinyl Fluoride (PVF)	Military	MIL-C-27500 MIL-W-81044
TE Connectivity AMP Connectors 81044/12-24-908	Copper Tinned	24 AWG	Hook-Up			0.003 in	0.076 mm	Black Gray White Stripe	600 V	0.04 in	1.02 mm	150 °C	-65 ░C	Polyvinylidene Fluoride (PVDF) Irradiated	Military	MIL-C-27500 MIL-W-81044
TE Connectivity AMP Connectors 81044/12-24-97	Copper Tinned	24 AWG	Hook-Up			0.0031 in	0.08 mm	White Violet Stripe	600 V	0.04 in	1.02 mm	150 °C	-65 ░C	Polyvinyl Fluoride (PVF)	Military	MIL-C-27500 MIL-W-81044
TE Connectivity AMP Connectors 81044/12-12-7	Copper Tinned	12 AWG	Hook-Up Dual Wall	37	28 AWG	0.003 in	0.076 mm	Violet	600 V	0.108 in	2.74 mm	200 °C	-65 ░C	Polyvinyl Fluoride (PVF)	Military	MIL-C-27500 MIL-W-81044
TE Connectivity AMP Connectors 81044/12-14-9	Copper Tinned	14.5 AWG	Hook-Up Dual Wall			0.003 in	0.076 mm	White	600 V	0.089 in	2.26 mm	200 °C	-65 ░C	Polyvinylidene Fluoride (PVDF)	Military	MIL-C-27500 MIL-W-81044	609.6 m	2000 ft	Enter Number of Feet in Order Quantity
TE Connectivity AMP Connectors 81044/12-26-6
TE Connectivity AMP Connectors 81044/12-14-8
TE Connectivity AMP Connectors 81044/12-22-914	Copper Tinned	22 AWG	Hook-Up	19	34 AWG	0.003 in	0.076 mm	Brown White Yellow Stripe	600 V	0.047 in	1.19 mm	150 °C	-65 ░C	Polyvinylidene Fluoride (PVDF) Irradiated	Military	MIL-C-27500 MIL-W-81044
