RAC05-K/C14 Series
Manufacturer: Recom Power
Beta
⌘K
AC/DC ENCLOSED POWER SUPPLY (PSU), ITE, 1 OUTPUTS, 5 W, 5 V, 1 A
| Part | Approval Agency | Efficiency | Voltage - Output 1 | Voltage - Isolation | Current - Output 1 | Features | Operating Temperature [Max] | Operating Temperature [Min] | Number of Outputs | Voltage - Input [Min] | Voltage - Input [Max] | Power (Watts) | Mounting Type | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Applications | Type | Minimum Load Required |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Recom Power | CB CE cURus FCC | 80 % | 5 V | 3000 V | 1 A | Universal Input | 70 °C | -25 °C | 1 | 85 VAC 120 VDC | 264 VAC 370 VDC | 5 W | Panel Mount | 2.17 " | 28.5 mm | 55.1 mm | 1.12 in | 0.83 " | 21 mm | ITE (Commercial) | Enclosed | |
 Recom Power | CB CE cURus FCC | 84 % | 24 V | 3000 V | 210 mA | Universal Input | 70 °C | -25 °C | 1 | 85 VAC 120 VDC | 264 VAC 370 VDC | 5 W | Panel Mount | 2.17 " | 28.5 mm | 55.1 mm | 1.12 in | 0.83 " | 21 mm | ITE (Commercial) | Enclosed | |
 Recom Power | CB CE cURus FCC | 76 % | 3.3 V | 3000 V | 1.51 A | Universal Input | 70 °C | -25 °C | 1 | 85 VAC 120 VDC | 264 VAC 370 VDC | 5 W | Panel Mount | 2.17 " | 28.5 mm | 55.1 mm | 1.12 in | 0.83 " | 21 mm | ITE (Commercial) | Enclosed | |
 Recom Power | CB CE cURus FCC | 81 % | 15 V | 3000 V | 333 mA | Universal Input | 70 °C | -25 °C | 1 | 85 VAC 120 VDC | 264 VAC 370 VDC | 5 W | Panel Mount | 2.17 " | 28.5 mm | 55.1 mm | 1.12 in | 0.83 " | 21 mm | ITE (Commercial) | Enclosed | |
 Recom Power | CB CE cURus FCC | 81 % | 12 V | 3000 V | 420 mA | Universal Input | 70 °C | -25 °C | 1 | 85 VAC 120 VDC | 264 VAC 370 VDC | 5 W | Panel Mount | 2.17 " | 28.5 mm | 55.1 mm | 1.12 in | 0.83 " | 21 mm | ITE (Commercial) | Enclosed |
