396-034 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 34POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row [custom] | Card Type | Contact Finish | Read Out | Termination | Contact Material | Number of Rows [custom] | Gender | Mounting Type | Pitch | Pitch | Contact Type | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Color | Features | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Number of Positions/Bay/Row | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | Non Specified - Dual Edge | Gold | Dual | Solder Wire Wrap | Copper Alloy | 2 | Female | Right Angle Through Hole | 3.18 mm | 0.125 in | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Black | Card Guides | -40 C | 105 ░C | 34 | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | Non Specified - Dual Edge | Gold | Dual | Solder | Copper Alloy | 2 | Female | Board Edge Straddle Mount | 3.18 mm | 0.125 in | Cantilever | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Black | Card Extender Card Guides | -40 C | 105 ░C | 34 | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | Non Specified - Dual Edge | Gold | Dual | Wire Wrap | Copper Alloy | 2 | Female | Through Hole | 3.18 mm | 0.125 in | Cantilever | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Black | -40 C | 105 ░C | 34 | ||||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | Non Specified - Dual Edge | Gold | Dual | Solder | Copper Alloy | 2 | Female | Board Edge Straddle Mount | 3.18 mm | 0.125 in | Cantilever | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | Black | Card Extender | -40 C | 105 ░C | 34 | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Gold | Single | Wire Wrap | Copper Alloy | Female | Through Hole | 3.18 mm | 0.125 in | Cantilever | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Black | -40 C | 105 ░C | 34 | 1 | 34 | 1 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Gold | Single | Solder | Copper Alloy | Female | Through Hole | 3.18 mm | 0.125 in | Cantilever | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Black | Card Guides | -40 C | 105 ░C | 34 | 1 | 34 | 1 | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | Non Specified - Dual Edge | Gold | Dual | Solder | Copper Alloy | 2 | Female | Board Edge Straddle Mount | 3.18 mm | 0.125 in | Cantilever | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Black | Card Extender | -40 C | 105 ░C | 34 | |||||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Gold | Single | Solder | Copper Alloy | Female | Through Hole | 3.18 mm | 0.125 in | Cantilever | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Black | -40 C | 105 ░C | 34 | 1 | 34 | 1 | ||||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | Non Specified - Dual Edge | Gold | Dual | Solder | Copper Alloy | 2 | Female | Board Edge Straddle Mount | 3.18 mm | 0.125 in | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Black | Card Extender | -40 C | 105 ░C | 34 | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | Non Specified - Dual Edge | Gold | Dual | Solder Wire Wrap | Copper Alloy | 2 | Female | Right Angle Through Hole | 3.18 mm | 0.125 in | Cantilever | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Black | Card Guides | -40 C | 105 ░C | 34 |
