MSS30 Series

Catalog

SCHOTTKY DIODE,BEAMLEAD,PACKAGE

Part	Diode Type	Operating Temperature [Max]	Operating Temperature [Min]	Current - Max [Max]	Capacitance @ Vr, F	Package / Case	Voltage - Peak Reverse (Max)	Power Dissipation (Max) [Max]	Resistance @ If, F	Supplier Device Package	Voltage - Peak Reverse (Max) [Max]
MACOM Technology Solutions MSS30-448-H47	Schottky - 1 Bridge	150 °C	-65 ░C	50 mA	0.26 pF	H40	2 V	100 mW	7 Ohm
MACOM Technology Solutions MSS30-B53-H40	Schottky - 1 Bridge				0.46 pF	H40	2 V
MACOM Technology Solutions MSS30-B53-E45	Schottky - 1 Bridge	150 °C	-65 ░C	50 mA	0.33 pF	E45		100 mW		E45	3 V
MACOM Technology Solutions MSS30-B46-B45	Schottky - 1 Bridge	150 °C	-65 ░C	50 mA	0.13 pF	E45		100 mW		E45	3 V
MACOM Technology Solutions MSS30-248-B20	Schottky - 1 Pair Series Connection	150 °C	-65 ░C	50 mA	0.15 pF	B20	2 V	100 mW	7 Ohm	B20
