4448/R Series

Manufacturer: Delevan

Catalog

COUPLED INDUCTORS 20UH 15% .085OHM HI CURRNT MOLDED SMT

Part	Shielding	DC Resistance (DCR) - Parallel	Mounting Type	Number of Coils	Inductance - Connected In Series	DC Resistance (DCR) - Series [Max]	Package / Case	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Operating Temperature [Min]	Operating Temperature [Max]	Current Rating - Parallel	Inductance - Connected In Parallel	Tolerance	Height	Height	DC Resistance (DCR) - Series	Current Rating - Series
Delevan 4448-18L	Unshielded	85 mOhm	Surface Mount	2	80 µH	340 mOhm	Nonstandard	0.53 "	13.46 mm	0.53 in	13.46 mm	-55 C	125 °C	1.9 A	20 µH	15 %	0.31 in	7.87 mm
Delevan 4448-12M	Unshielded	33 mOhm	Surface Mount	2	32 µH		Nonstandard	0.53 "	13.46 mm	0.53 in	13.46 mm	-55 C	125 °C	3 A	8 µH	20 %	0.31 in	7.87 mm	132 mOhm	1.5 A
Delevan 4448-112M	Unshielded	19 mOhm	Surface Mount	2	32 µH	76 mOhm	Nonstandard	0.53 "	13.46 mm	0.53 in	13.46 mm	-55 C	125 °C	3.5 A	8 µH	20 %	0.31 in	7.87 mm		1.75 A
Delevan 4448R-118L	Unshielded	55 mOhm	Surface Mount	2	80 µH		Nonstandard	0.53 "	13.46 mm	0.53 in	13.46 mm	-55 C	125 °C	2.1 A	20 µH	15 %	0.31 in	7.87 mm	220 mOhm	1.05 A
Delevan 4448-22L	Unshielded	166 mOhm	Surface Mount	2	132 µH	664 mOhm	Nonstandard	0.53 "	13.46 mm	0.53 in	13.46 mm	-55 C	125 °C	1.3 A	33 µH	15 %	0.31 in	7.87 mm		650 mA
Delevan 4448-124L	Unshielded	111 mOhm	Surface Mount	2	200 µH	444 mOhm	Nonstandard	0.53 "	13.46 mm	0.53 in	13.46 mm	-55 C	125 °C	1.5 A	50 µH	15 %	0.31 in	7.87 mm		750 mA
