TL2BR Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
SMD CURRENT SENSE RESISTORS, TL SERIES, 0.018 OHM, 250 MW, - 1%, 1206 [3216 METRIC]
| Part | Features | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Tolerance | Resistance | Supplier Device Package | Power (Watts) | Power (Watts) | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Temperature Coefficient | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Number of Terminations [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Current Sense | -65 ░C | 170 °C | 1206 (3216 Metric) | 1 % | 18 mOhms | 1206 | 0.25 W | 0.25 W | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | 75 ppm/°C | 0.6 mm | 0.024 in | 2 |
TE Connectivity AMP Connectors | Current Sense | -65 ░C | 170 °C | 1206 (3216 Metric) | 1 % | 33 mOhms | 1206 | 0.25 W | 0.25 W | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | 75 ppm/°C | 0.6 mm | 0.024 in | 2 |
 TE Connectivity AMP Connectors | Current Sense | -65 ░C | 170 °C | 1206 (3216 Metric) | 1 % | 15 mOhms | 1206 | 0.25 W | 0.25 W | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | 75 ppm/°C | 0.6 mm | 0.024 in | 2 |
TE Connectivity AMP Connectors | Current Sense | -65 ░C | 170 °C | 1206 (3216 Metric) | 1 % | 0.068 Ohms | 1206 | 0.25 W | 0.25 W | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | 75 ppm/°C | 0.6 mm | 0.024 in | 2 |
TE Connectivity AMP Connectors | Current Sense | -65 ░C | 170 °C | 1206 (3216 Metric) | 1 % | 10 mOhms | 1206 | 0.25 W | 0.25 W | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | 75 ppm/°C | 0.6 mm | 0.024 in | 2 |
TE Connectivity AMP Connectors | Current Sense | -65 ░C | 170 °C | 1206 (3216 Metric) | 1 % | 15 mOhms | 1206 | 0.25 W | 0.25 W | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | 75 ppm/°C | 0.6 mm | 0.024 in | 2 |
TE Connectivity AMP Connectors | Current Sense | -65 ░C | 170 °C | 1206 (3216 Metric) | 1 % | 25 mOhms | 1206 | 0.25 W | 0.25 W | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | 75 ppm/°C | 0.6 mm | 0.024 in | 2 |
TE Connectivity AMP Connectors | Current Sense | -65 ░C | 170 °C | 1206 (3216 Metric) | 1 % | 47 mOhms | 1206 | 0.25 W | 0.25 W | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | 75 ppm/°C | 0.6 mm | 0.024 in | 2 |
 TE Connectivity AMP Connectors | Current Sense | -65 ░C | 170 °C | 1206 (3216 Metric) | 1 % | 22 mOhms | 1206 | 0.25 W | 0.25 W | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | 75 ppm/°C | 0.6 mm | 0.024 in | 2 |
TE Connectivity AMP Connectors | Current Sense | -65 ░C | 170 °C | 1206 (3216 Metric) | 1 % | 75 mOhms | 1206 | 0.25 W | 0.25 W | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | 75 ppm/°C | 0.6 mm | 0.024 in | 2 |
