895-046 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 46POS 0.100
...
| Part | Material - Insulation | Termination Rows [custom] | Number of Rows [custom] | Termination | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Color | Read Out | Card Type | Gender | Contact Material | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Number of Positions | Flange Feature | Mounting Type | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | Solder | Gold | 0.25 Ám | 10 Áin | Black | Dual | Non Specified - Dual Edge | Female | Copper Alloy | 23 | 125 °C | -40 C | 0.1 " | 2.54 mm | 46 | M3 Threaded Insert Top Mount Opening | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | Solder | Gold | 0.25 Ám | 10 Áin | Black | Dual | Non Specified - Dual Edge | Female | Copper Alloy | 23 | 125 °C | -40 C | 0.1 " | 2.54 mm | 46 | 4-40 Threaded Insert Top Mount Opening | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Wire Wrap | Gold | 0.25 Ám | 10 Áin | Black | Single | Non Specified - Single Edge | Female | Copper Alloy | 46 | 125 °C | -40 C | 0.1 " | 2.54 mm | 46 | 4-40 Threaded Insert Top Mount Opening | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | Solder Eyelet(s) | Gold | 0.25 Ám | 10 Áin | Black | Dual | Non Specified - Dual Edge | Female | Copper Alloy | 23 | 125 °C | -40 C | 0.1 " | 2.54 mm | 46 | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | Wire Wrap | Gold | 0.25 Ám | 10 Áin | Black | Dual | Non Specified - Dual Edge | Female | Copper Alloy | 23 | 125 °C | -40 C | 0.1 " | 2.54 mm | 46 | Flush Mount Side Opening Unthreaded | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder Eyelet(s) | Gold | 0.25 Ám | 10 Áin | Black | Single | Non Specified - Single Edge | Female | Copper Alloy | 46 | 125 °C | -40 C | 0.1 " | 2.54 mm | 46 | M3 Threaded Insert Top Mount Opening | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | Solder | Gold | 0.25 Ám | 10 Áin | Black | Dual | Non Specified - Dual Edge | Female | Copper Alloy | 23 | 125 °C | -40 C | 0.1 " | 2.54 mm | 46 | Floating Bobbin Flush Mount | Right Angle Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2.95 mm | 0.116 " | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | Wire Wrap | Gold | 0.25 Ám | 10 Áin | Black | Dual | Non Specified - Dual Edge | Female | Copper Alloy | 23 | 125 °C | -40 C | 0.1 " | 2.54 mm | 46 | Flush Mount Top Opening Unthreaded | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | Wire Wrap | Gold | 0.25 Ám | 10 Áin | Black | Dual | Non Specified - Dual Edge | Female | Copper Alloy | 23 | 125 °C | -40 C | 0.1 " | 2.54 mm | 46 | Side Mount Opening Unthreaded | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | Solder Eyelet(s) | Gold | 0.25 Ám | 10 Áin | Black | Dual | Non Specified - Dual Edge | Female | Copper Alloy | 23 | 125 °C | -40 C | 0.1 " | 2.54 mm | 46 | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
