AM15E Series
Manufacturer: DComponents
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
DC DC CONVERTER +/-24V 15W
| Part | Standard Number | Voltage - Isolation | Voltage - Input (Max) | Type | Size / Dimension Width | Size / Dimension Length | Size / Dimension Height | Power (Watts) | Voltage - Output 2 | Voltage - Input (Min) | Operating Temperature (Min) | Operating Temperature (Max) | Mounting Type | Current - Output (Max) | Voltage - Output 1 (Min) | Voltage - Output 1 (Max) | Efficiency | Applications | Approval Agency | Number of Outputs | Features | Package Leads | Package Name | Voltage - Output 1 | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 DComponents | 62368-1 | 1500 Vrns | 18 V | Isolated Module | 1 in | 2 in | 0.4 in | 15 W | -24 V | 9 V | -40 °C | 85 °C | Through Hole | 310 mA | -24 V | 24 V | 85 % | ITE (Commercial) | CE cULus cURus EN IEC UL | 2 | |||||
 DComponents | 62368-1 | 1500 Vrns | 36 V | Isolated Module | 1 in | 2 in | 0.4 in | 15 W | 9 V | -40 °C | 85 °C | Through Hole | 1.25 A | 85 % | ITE (Commercial) | CE cULus cURus EN IEC UL | 1 | Remote On/Off | 5 Leads | 6-DIP Module | 12 V | ||||
 DComponents | 62368-1 | 1500 Vrns | 18 V | Isolated Module | 1 in | 2 in | 0.4 in | 15 W | -15 V | 9 V | -40 °C | 85 °C | Through Hole | 500 mA | 84 % | ITE (Commercial) | CE cULus cURus EN IEC UL | 2 | 15 V | 5-DIP Module |
