CHV-ST Series
Manufacturer: Bourns Inc.
Beta
⌘K
THICK FILM RESISTORS - SMD RESHV ST 0603 200K 1 % 0.1W TCR100
| Part | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Number of Terminations [custom] | Package / Case | Package / Case | Temperature Coefficient | Tolerance | Power (Watts) | Power (Watts) | Operating Temperature [Max] | Operating Temperature [Min] | Composition | Resistance | Features | Size / Dimension [y] | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 0.031 in | 1.6 mm | 0.8 mm | 0.063 " | 0.55 mm | 0.022 in | 2 | 1608 Metric | 0603 | 100 ppm/°C | 1 % | 0.1 W | 0.1 W | 155 C | -55 C | Thick Film | 200000 Ohms | High Voltage | ||
 Bourns Inc. | 0.049 " | 2 mm | 0.079 in | 0.6 mm | 0.024 in | 2 | 0805 | 100 ppm/°C | 1 % | 0.125 W | 0.125 W | 155 C | -55 C | Thick Film | 2 MOhms | High Voltage | 1.25 mm | 0805 | ||
 Bourns Inc. | 0.049 " | 2 mm | 0.079 in | 0.6 mm | 0.024 in | 2 | 0805 | 100 ppm/°C | 1 % | 0.125 W | 0.125 W | 155 C | -55 C | Thick Film | 4.99 MOhms | High Voltage | 1.25 mm | 0805 |
