TWA-Y Series

Catalog

TANTALUM CAPACITORS - WET WET TANT HIGH TEMP

Part	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Capacitance	Failure Rate	ESR (Equivalent Series Resistance)	Type	Voltage - Rated	Lifetime @ Temp.	Mounting Type	Manufacturer Size Code	Size / Dimension [z]	Size / Dimension [diameter]	Features	Tolerance	Size / Dimension [x]	Size / Dimension [diameter]	Size / Dimension [x]	Size / Dimension [z]
KYOCERA AVX TWAE687K075SBYZ0000	Axial Can	200 °C	-55 C	680 µF	Z	900 mOhm	Hermetically Sealed	75 V	500 Hrs	Through Hole	E	1.062 in 26.97 mm	0.406 " 10.31 mm	Wet Tantalum	10 %
KYOCERA AVX TWAD227M060CBYZ0700	Axial Can	200 °C	-55 C	220 µF	Z	1.8 Ohm	Hermetically Sealed	60 VDC	2000 Hrs	Through Hole	D		0.375 "	Wet Tantalum	20 %	19.46 mm	9.52 mm	0.766 in
KYOCERA AVX TWAE757K100SBYZ0700	Axial Can	200 °C	-55 C	750 µF	Z	600 mOhm	Hermetically Sealed	100 V	500 Hrs	Through Hole	E	1.062 in 26.97 mm	0.406 " 10.31 mm	Wet Tantalum	10 %
KYOCERA AVX TWAE757K075CBYZ0000	Axial Can	200 °C	-55 C	750 µF	Z	700 mOhm	Hermetically Sealed	75 V	500 Hrs	Through Hole	E	1.062 in	0.375 "	Wet Tantalum	10 %		9.52 mm		26.97 mm
KYOCERA AVX TWAE337K050SBYZ0000	Axial Can	200 °C	-55 C	330 µF	Z	1.5 Ohm	Hermetically Sealed	50 VDC	2000 Hrs	Through Hole	E	1.062 in 26.97 mm	0.406 " 10.31 mm	Wet Tantalum	10 %
KYOCERA AVX TWAA336M050SBYZ0700
KYOCERA AVX TWAA156M030CBYZ0700
KYOCERA AVX TWAB506K060SBYZ0000
KYOCERA AVX TWAB127M050SBYZ0000
KYOCERA AVX TWAA226M060SBYZ0700
