RF Connectors / Coaxial Connectors SMB RIGHT ANGLE,PCB
RF Connectors / Coaxial Connectors SMB RIGHT ANGLE,PCB
| Part | Housing Color | Frequency - Max [Max] | Contact Termination | Center Contact Material | Impedance | Mounting Type | Shield Termination | Connector Style | Number of Ports | Fastening Type | Connector Type | Features | Length | Length | 1st Connector | Style | Overall Impedance | 2nd Connector | Cable Impedance | 1st Connector Mounting Type | Cable Type | 1st Contact Gender |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Black | 6000 MHz | Solder | Phosphor Bronze | 50 Ohms | Right Angle Through Hole | Solder | Fakra SMB | 1 | Locking Ramp | Jack Male Pin | Code A | ||||||||||
 Molex | 39.4 in | 3.3 ft | Fakra Plug | Fakra to Cable | 50 Ohms | Cable (Round) | 50 Ohms | Free Hanging (In-Line) | RG-316 | Male | ||||||||||||
 Molex | Gold | 4 GHz | Solder | Brass | 75 Ohms | Board Edge End Launch | Solder | SMB | 1 | Snap-On | Jack Male Pin |
