FDZ25 Series

Catalog

MOSFET 2P-CH 20V 6.5A 18BGA

Part	Gate Charge (Qg) (Max) @ Vgs	Input Capacitance (Ciss) (Max) @ Vds	Power - Max [Max]	Supplier Device Package	Supplier Device Package [y]	Supplier Device Package [x]	Operating Temperature [Min]	Operating Temperature [Max]	Current - Continuous Drain (Id) @ 25°C	Technology	Package / Case	Drain to Source Voltage (Vdss)	Configuration	FET Feature	Rds On (Max) @ Id, Vgs	Mounting Type	Vgs(th) (Max) @ Id	Gate Charge (Qg) (Max) @ Vgs [Max]
ON Semiconductor FDZ2554PZ	21 nC	1430 pF	2.1 W	18-BGA	4 mm	2.5 mm	-55 °C	150 °C	6.5 A	MOSFET (Metal Oxide)	18-WFBGA	20 V	2 P-Channel	Logic Level Gate	28 mOhm	Surface Mount	1.5 V
ON Semiconductor FDZ2553N		1299 pF	2.1 W	18-BGA	4 mm	2.5 mm	-55 °C	150 °C	9.6 A	MOSFET (Metal Oxide)	18-WFBGA	20 V	2 N-Channel (Dual)	Logic Level Gate	14 mOhm	Surface Mount	1.5 V	17 nC
ON Semiconductor FDZ2553NZ		1240 pF	2.1 W	18-BGA	4 mm	2.5 mm	-55 °C	150 °C	9.6 A	MOSFET (Metal Oxide)	18-WFBGA	20 V	2 N-Channel (Dual)	Logic Level Gate	14 mOhm	Surface Mount	1.5 V	18 nC
