68439 Series

Catalog

CONN HEADER VERT 72POS 2.54MM

Part	Mounting Type	Fastening Type	Number of Positions	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Pitch - Mating	Pitch - Mating	Contact Type	Material Flammability Rating	Number of Rows	Contact Material	Contact Length - Mating [x]	Contact Length - Mating [x]	Termination	Insulation Height	Insulation Height	Connector Type	Contact Shape	Shrouding	Number of Positions Loaded	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Overall Contact Length	Overall Contact Length	Contact Length - Post [x]	Contact Length - Post [x]	Insulation Color	Contact Finish - Mating	Contact Finish - Post
Amphenol ICC (FCI) 68439-472	Through Hole	Push-Pull	72	2.54 çm	100 çin	0.1 in	2.54 mm	Male Pin	UL94 V-0	2	Phosphor Bronze	0.5 in	12.7 mm	Solder	0.1 in	2.54 mm	Header	Square	Unshrouded	All	2.54 mm	0.1 in	0.72 "	18.29 mm	0.12 in	3.05 mm	Black
Amphenol ICC (FCI) 68439-172HLF	Through Hole	Push-Pull	72	0.76 Ám	30 Áin	0.1 in	2.54 mm	Male Pin	UL94 V-0	2	Phosphor Bronze	0.5 in	12.7 mm	Solder	0.1 in	2.54 mm	Header	Square	Unshrouded	All	2.54 mm	0.1 in	0.72 "	18.29 mm	0.12 in	3.05 mm	Black	Gold or Gold GXT™
Amphenol ICC (FCI) 68439-272	Through Hole	Push-Pull	72	0.38 µm	15 µin	0.1 in	2.54 mm	Male Pin	UL94 V-0	2	Phosphor Bronze	0.5 in	12.7 mm	Solder	0.1 in	2.54 mm	Header	Square	Unshrouded	All	2.54 mm	0.1 in	0.72 "	18.29 mm	0.12 in	3.05 mm	Black	Gold or Gold GXT™
Amphenol ICC (FCI) 68439-472HLF	Through Hole	Push-Pull	72	2.54 çm	100 çin	0.1 in	2.54 mm	Male Pin	UL94 V-0	2	Phosphor Bronze	0.5 in	12.7 mm	Solder	0.1 in	2.54 mm	Header	Square	Unshrouded	All	2.54 mm	0.1 in	0.72 "	18.29 mm	0.12 in	3.05 mm	Black		Tin
Amphenol ICC (FCI) 68439-372	Through Hole	Push-Pull	72	1.27 µm	50 µin	0.1 in	2.54 mm	Male Pin	UL94 V-0	2	Phosphor Bronze	0.5 in	12.7 mm	Solder	0.1 in	2.54 mm	Header	Square	Unshrouded	All	2.54 mm	0.1 in	0.72 "	18.29 mm	0.12 in	3.05 mm	Black	Gold or Gold GXT™
Amphenol ICC (FCI) 68439-172H	Through Hole	Push-Pull	72	0.76 Ám	30 Áin	0.1 in	2.54 mm	Male Pin	UL94 V-0	2	Phosphor Bronze	0.5 in	12.7 mm	Solder	0.1 in	2.54 mm	Header	Square	Unshrouded	All	2.54 mm	0.1 in	0.72 "	18.29 mm	0.12 in	3.05 mm	Black	Gold or Gold GXT™
