6823 Series

Catalog

HOOK-UP STRND 22AWG WHT 1000'

Part	Voltage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Wire Gauge	Jacket Color	Cable Type	Length	Length	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Material	Length [x]	Length [x]
ALPHA WIRE 6823 WH001	300 VDC	1.17 mm	0.046 in	22 AWG	White	Hook-Up	304.8 m	1000 ft	0.2 mm	0.008 in	30 AWG	7	Polyphenylene Ether (PPE)	-40 C	110 °C	Copper Bare
ALPHA WIRE 6823 BR005	300 VDC	1.17 mm	0.046 in	22 AWG	Brown	Hook-Up			0.2 mm	0.008 in	30 AWG	7	Polyphenylene Ether (PPE)	-40 C	110 °C	Copper Bare	100 ft	30.5 m
ALPHA WIRE 6823 BL001	300 VDC	1.17 mm	0.046 in	22 AWG	Blue	Hook-Up	304.8 m	1000 ft	0.2 mm	0.008 in	30 AWG	7	Polyphenylene Ether (PPE)	-40 C	110 °C	Copper Bare
ALPHA WIRE 6823 RD001	300 VDC	1.17 mm	0.046 in	22 AWG	Red	Hook-Up	304.8 m	1000 ft	0.2 mm	0.008 in	30 AWG	7	Polyphenylene Ether (PPE)	-40 C	110 °C	Copper Bare
ALPHA WIRE 6823 GR001	300 VDC	1.17 mm	0.046 in	22 AWG	Green	Hook-Up	304.8 m	1000 ft	0.2 mm	0.008 in	30 AWG	7	Polyphenylene Ether (PPE)	-40 C	110 °C	Copper Bare
ALPHA WIRE 6823 GY005	300 VDC	1.17 mm	0.046 in	22 AWG	Green Yellow Stripe	Hook-Up			0.2 mm	0.008 in	30 AWG	7	Polyphenylene Ether (PPE)	-40 C	110 °C	Copper Bare	100 ft	30.5 m
ALPHA WIRE 6823 BK005	300 VDC	1.17 mm	0.046 in	22 AWG	Black	Hook-Up			0.2 mm	0.008 in	30 AWG	7	Polyphenylene Ether (PPE)	-40 C	110 °C	Copper Bare	100 ft	30.5 m
ALPHA WIRE 6823 OR005	300 VDC	1.17 mm	0.046 in	22 AWG	Orange	Hook-Up			0.2 mm	0.008 in	30 AWG	7	Polyphenylene Ether (PPE)	-40 C	110 °C	Copper Bare	100 ft	30.5 m
ALPHA WIRE 6823 GY001	300 VDC	1.17 mm	0.046 in	22 AWG	Green Yellow Stripe	Hook-Up	304.8 m	1000 ft	0.2 mm	0.008 in	30 AWG	7	Polyphenylene Ether (PPE)	-40 C	110 °C	Copper Bare
ALPHA WIRE 6823 RD005	300 VDC	1.17 mm	0.046 in	22 AWG	Red	Hook-Up			0.2 mm	0.008 in	30 AWG	7	Polyphenylene Ether (PPE)	-40 C	110 °C	Copper Bare	100 ft	30.5 m
