1735360 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN FFC FPC BOTTOM 28POS 1MM RA
| Part | Number of Positions | Flat Flex Type | Voltage Rating | Cable End Type | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Housing Material | FFC, FCB Thickness | Mounting Type | Pitch [x] | Pitch [x] | Contact Material | Connector/Contact Type | Housing Color | Height Above Board | Height Above Board | Contact Finish Thickness | Contact Finish Thickness | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | 28 | FFC FPC | 125 VDC | Straight | Solder | 85 °C | -20 C | Tin | Polyamide (PA) Nylon Glass Filled | 0.3 mm | Surface Mount Right Angle | 0.039 in | 1 mm | Phosphor Bronze | Contacts Bottom | Beige | 0.118 in | 3 mm | |||
TE Connectivity Raychem Cable Protection | FFC FPC | 125 VDC | Straight | Solder | 85 °C | -20 C | Tin | Polyamide (PA) Nylon Glass Filled | 0.3 mm | Surface Mount Right Angle | 0.039 in | 1 mm | Phosphor Bronze | Contacts Bottom | Beige | 0.118 in | 3 mm | 39.4 Áin | 1 Ám | 16 |
