Z-PACK 2mm HM Series
Hard Metric Connectors 154P VERT PLUG ZPACK
Manufacturer: TE Connectivity Raychem Cable Protection
Catalog
Hard Metric Connectors 154P VERT PLUG ZPACK
Beta
⌘K
Hard Metric Connectors 154P VERT PLUG ZPACK
Hard Metric Connectors 154P VERT PLUG ZPACK
Hard Metric Connectors 154P VERT PLUG ZPACK
| Part | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Number of Rows | Pitch [x] | Pitch [x] | Mounting Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Voltage Rating | Contact Finish | Connector Type | Number of Positions Loaded | Connector Style | Accessory Type | For Use With/Related Products | Specifications | Number of Positions [custom] | Number of Positions [custom] | Connector Usage | Features | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Press-Fit | -55 °C | 125 °C | 1.5 A | 8 | 0.079 in | 2 mm | Board Edge Right Angle Through Hole | 88 | 0.76 Ám | 30 Áin | 750 Vrms | Gold | Receptacle Female Sockets | All | F 11 | ||||||||
TE Connectivity Raychem Cable Protection | Coding Keys | Z-Pack Series | Gray | |||||||||||||||||||||
TE Connectivity Raychem Cable Protection | Coding Keys | Z-Pack Series | Brown | |||||||||||||||||||||
TE Connectivity Raychem Cable Protection | Coding Keys | Z-Pack Series | Orange | |||||||||||||||||||||
 TE Connectivity Raychem Cable Protection | Press-Fit | -55 °C | 125 °C | 1.5 A | 2 5 | 0.079 in | 2 mm | Through Hole | 500 VAC | Gold | Header Male Pins | All | AB 19 | 95 | 32 | CompactPCI | ||||||||
 TE Connectivity Raychem Cable Protection | Press-Fit | -55 °C | 125 °C | 1.5 A | 5 | 0.079 in | 2 mm | Through Hole Right Angle | 110 positions | 0.76 Ám | 30 Áin | 500 VAC | Gold | Receptacle Female Sockets | All | A 22 | CompactPCI J1/J4 | Upper Shield | ||||||
 TE Connectivity Raychem Cable Protection | Solder | -20 C | 85 °C | 1 A | 5 | 0.079 in | 2 mm | Free Hanging (In-Line) | 40 | 0.76 Ám | 30 Áin | 40 V | Gold | Receptacle Female Sockets | All | Shielded | ||||||||
 TE Connectivity Raychem Cable Protection | Press-Fit | -55 °C | 125 °C | 1.5 A | 0.079 in | 2 mm | Through Hole | 50 200 | 0.76 Ám | 30 Áin | 750 Vrms | Gold | Header Male Pins | All | E 25 | Backplane | Alignment Strip | |||||||
 TE Connectivity Raychem Cable Protection | Coding Keys | Z-Pack Series | Blue | |||||||||||||||||||||
 TE Connectivity Raychem Cable Protection | Press-Fit | -55 °C | 125 °C | 1.5 A | 2 5 | 0.079 in | 2 mm | Through Hole | 500 VAC | Gold | Header Male Pins | All | B 19 | 38 | Backplane | 95 |
