5962-0 Series
Manufacturer: Broadcom Limited
Beta
⌘K
LOGIC OUTPUT OPTOCOUPLERS 3.3V 1CH 1500VDC HERMETICALLY SEALED
| Part | Current - Output / Channel | Package / Case | Current - DC Forward (If) (Max) [Max] | Voltage - Output (Max) [Max] | Turn On / Turn Off Time (Typ) | Current Transfer Ratio (Min) | Input Type | Voltage - Isolation | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Number of Channels [custom] | Voltage - Forward (Vf) (Typ) | Supplier Device Package | Output Type | Rise / Fall Time (Typ) | Rise / Fall Time (Typ) | Technology | Common Mode Transient Immunity (Min) [Min] | Current - Output High, Low [custom] | Current - Output High, Low [custom] | Voltage - Output Supply [Min] | Voltage - Output Supply [Max] | Current - Peak Output | Pulse Width Distortion (Max) [Max] | Propagation Delay tpLH / tpHL (Max) [custom] | Propagation Delay tpLH / tpHL (Max) [custom] | Number of Channels | Data Rate | Voltage - Supply [Max] | Voltage - Supply [Min] | Inputs - Side 1/Side 2 [custom] | Inputs - Side 1/Side 2 [custom] | Propagation Delay tpLH / tpHL (Max) [Max] | Rise / Fall Time (Typ) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Broadcom Limited | 40 mA | 8-SMD Butt Joint | 10 mA | 20 V | 2 µs 6 µs | 200 % | DC | 1.5 kV | -55 C | 125 °C | Surface Mount | 1 | 1.4 V | 8-DIP Butt Joint | Darlington | ||||||||||||||||||||
Broadcom Limited | 8-SMD Butt Joint | 25 mA | 1.5 kV | -55 C | 125 °C | Surface Mount | 1 | 1.5 V | 8-DIP Butt Joint | 100 ns | 100 ns | Optical Coupling | 10 kV/µs | 500 mA | 500 mA | 15 V | 30 V | 600 mA | 300 ns | 500 ns | 500 ns | ||||||||||||||
 Broadcom Limited | 40 mA | 8-DIP (0.300" 7.62mm) | 10 mA | 20 V | 2 µs 6 µs | 200 % | DC | 1.5 kV | -55 C | 125 °C | Through Hole | 1 | 1.4 V | 8-DIP | Darlington | ||||||||||||||||||||
 Broadcom Limited | 40 mA | 8-DIP (0.300" 7.62mm) | 10 mA | 20 V | 2 µs 6 µs | 200 % | DC | 1.5 kV | -55 C | 125 °C | Through Hole | 1.4 V | 8-DIP | Darlington | 2 | ||||||||||||||||||||
Broadcom Limited | 40 mA | 16-SMD Butt Joint | 10 mA | 20 V | 2 µs 6 µs | 200 % | DC | 1.5 kV | -55 C | 125 °C | Surface Mount | 4 | 1.4 V | 16-SMD Butt Joint | Darlington | ||||||||||||||||||||
Broadcom Limited | 25 mA | 8-DIP (0.300" 7.62mm) | 20 mA | DC | 1.5 kV | -55 C | 125 °C | Through Hole | 1 | 1.55 V | 8-DIP | Open Collector Schottky Clamped | 1 kV/µs | 10 Mbps | 3.6 V | 3 V | 1 | 0 | 100 ns | 8 ns 20 ns | |||||||||||||||
Broadcom Limited | 25 mA | 8-DIP (0.300" 7.62mm) | 20 mA | DC | 1.5 kV | -55 C | 125 °C | Through Hole | 1.55 V | 8-DIP | Open Collector Schottky Clamped | 1 kV/µs | 2 | 10 Mbps | 3.6 V | 3 V | 2 | 0 | 100 ns | 8 ns 20 ns |
