625 SERIES RIGHT ANGLE D-SUB PLU
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Color | Connector Type | Connector Style | Contact Finish Thickness | Backset Spacing | Backset Spacing | Mounting Type | Shell Material, Finish | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Termination | Number of Rows [custom] | Flange Feature | Contact Type | Material Flammability Rating | Current Rating (Amps) | Features | Number of Positions | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | Plug Male Pins | D-Sub | Flash | 0.584 " | 14.84 mm | Board Edge Right Angle Through Hole | Nickel Plated Steel | 1 | DE E | Solder | 2 | Housing/Shell (M3) | Signal | UL94 V-0 | 3 A | Board Lock Grounding Indents Mounting Brackets Shielded | 9 | Gold | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Board Edge Right Angle Through Hole | Nickel Plated Steel | 1 | DE E | Solder | 2 | Housing/Shell (Unthreaded) | Signal | UL94 V-0 | 3 A | Board Lock Grounding Indents Mounting Brackets Shielded | 9 | Gold | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Copper Alloy | Black | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Board Edge Right Angle Through Hole | Nickel Plated Steel | 1 | DE E | Solder | 2 | Housing/Shell (M3) | Signal | UL94 V-0 | 3 A | Grounding Indents Mounting Brackets Shielded | 9 | Gold | 15 µin | 0.38 µm | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Copper Alloy | Black | Plug Male Pins | D-Sub | Flash | 0.584 " | 14.84 mm | Board Edge Right Angle Through Hole | Nickel Plated Steel | 1 | DE E | Solder | 2 | Housing/Shell | Signal | UL94 V-0 | 3 A | Board Lock Grounding Indents Mounting Brackets Shielded | 9 | Gold | 4-40 | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Copper Alloy | Black | Plug Male Pins | D-Sub | Flash | 0.584 " | 14.84 mm | Board Edge Right Angle Through Hole | Nickel Plated Steel | 1 | DE E | Solder | 2 | Housing/Shell (Unthreaded) | Signal | UL94 V-0 | 3 A | Board Lock Grounding Indents Mounting Brackets Shielded | 9 | Gold | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | Plug Male Pins | D-Sub | Flash | 0.584 " | 14.84 mm | Board Edge Right Angle Through Hole | Nickel Plated Steel | 1 | DE E | Solder | 2 | Housing/Shell | Signal | UL94 V-0 | 3 A | Board Lock Grounding Indents Mounting Brackets Shielded | 9 | Gold | 4-40 | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | Plug Male Pins | D-Sub | Flash | 0.584 " | 14.84 mm | Board Edge Right Angle Through Hole | Nickel Plated Steel | 1 | DE E | Solder | 2 | 4-40 | Signal | UL94 V-0 | 3 A | Board Lock Grounding Indents Mounting Brackets Shielded | 9 | Gold | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Board Edge Right Angle Through Hole | Nickel Plated Steel | 1 | DE E | Solder | 2 | 4-40 Mating Side Female Screwlock | Signal | UL94 V-0 | 3 A | Grounding Indents Mounting Brackets Shielded | 9 | Gold | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Copper Alloy | Black | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Board Edge Right Angle Through Hole | Nickel Plated Steel | 1 | DE E | Solder | 2 | Housing/Shell (M3) | Signal | UL94 V-0 | 3 A | Board Lock Grounding Indents Mounting Brackets Shielded | 9 | Gold | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Copper Alloy | Black | Plug Male Pins | D-Sub | Flash | 0.584 " | 14.84 mm | Board Edge Right Angle Through Hole | Nickel Plated Steel | 1 | DE E | Solder | 2 | 4-40 Mating Side Female Screwlock | Signal | UL94 V-0 | 3 A | Board Lock Grounding Indents Mounting Brackets Shielded | 9 | Gold |
