395-037 Series
Manufacturer: EDAC Inc.
Beta
⌘K
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Material - Insulation | Termination Rows | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Contact Type | Card Type | Card Thickness [Max] | Card Thickness [Min] | Gender | Color | Termination | Mounting Type | Number of Rows | Contact Finish | Read Out | Pitch | Pitch | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | 37 | Cantilever | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | Solder | Right Angle Through Hole | 1 | Gold | Single | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 37 | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | 37 | Cantilever | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | Solder | Through Hole | 1 | Gold | Single | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 37 | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | 37 | Cantilever | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | Wire Wrap | Through Hole | 1 | Gold | Single | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 37 | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | 37 | Cantilever | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | Solder | Through Hole | 1 | Gold | Single | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 37 | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | 37 | Cantilever | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | Solder | Right Angle Through Hole | 1 | Gold | Single | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 37 | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | 37 | Cantilever | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | Solder | Right Angle Through Hole | 1 | Gold | Single | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 37 | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | 37 | Cantilever | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | Wire Wrap | Through Hole | 1 | Gold | Single | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 37 | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | 37 | Cantilever | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | Wire Wrap | Through Hole | 1 | Gold | Single | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 37 | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | 37 | Cantilever | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | Solder | Right Angle Through Hole | 1 | Gold | Single | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 37 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | 37 | Cantilever | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | Solder | Right Angle Through Hole | 1 | Gold | Single | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | M3 Threaded Insert Top Mount Opening | 37 |
