L77DB25 Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
CONN D-SUB RCPT 25POS R/A SLDR
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Dielectric Material | Voltage Rating | Color | Contact Finish | Material Flammability Rating | Backset Spacing | Backset Spacing | Features | Connector Type | Flange Feature | Current Rating (Amps) | Contact Finish Thickness | Contact Finish Thickness | Termination | Number of Rows [custom] | Mounting Type | Connector Style | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Number of Positions | Contact Type | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | -55 C | 125 °C | Brass | Thermoplastic Glass Filled | 300 VDC | Black | Gold | UL94 V-0 | 10.3 mm | 0.406 in | Mounting Brackets | Receptacle Female Sockets | 4-40 Mating Side Female Screwlock | 7.5 A | 0.203 çm | 8 µin | Solder | 2 | Right Angle Through Hole | D-Sub | B DB | 3 | 25 | Signal | |
 Amphenol ICC (Commercial Products) | -55 C | 125 °C | Brass | Thermoplastic Glass Filled | 300 VDC | Black | Gold | UL94 V-0 | Receptacle Female Sockets | Housing/Shell (Unthreaded) | 7.5 A | 0.203 çm | 8 µin | Solder | 2 | Through Hole | D-Sub | B DB | 3 | 25 | Signal | ||||
Amphenol ICC (Commercial Products) | -55 C | 125 °C | Brass | Thermoplastic Glass Filled | 300 VDC | Black | Gold | UL94 V-0 | 8.1 mm | 0.319 in | Receptacle Female Sockets | 4-40 Mating Side Female Screwlock | 7.5 A | 0.203 çm | 8 µin | Solder | 2 | Right Angle Through Hole | D-Sub | B DB | 3 | 25 | Signal | ||
Amphenol ICC (Commercial Products) | -55 C | 125 °C | Brass | Thermoplastic Glass Filled | 300 VDC | Black | Gold | UL94 V-0 | 8.1 mm | 0.319 in | Mounting Brackets | Receptacle Female Sockets | Housing/Shell (Unthreaded) | 7.5 A | 0.203 çm | 8 µin | Solder | 2 | Right Angle Through Hole | D-Sub | B DB | 3 | 25 | Signal | |
Amphenol ICC (Commercial Products) | -55 C | 125 °C | Brass | Thermoplastic Glass Filled | 300 VDC | Black | Gold | UL94 V-0 | Receptacle Female Sockets | Housing/Shell (Unthreaded) | 7.5 A | 0.38 µm | 15 µin | Screw | 2 | Free Hanging (In-Line) | D-Sub | B DB | 3 | 25 | Signal | 18 AWG | |||
 Amphenol ICC (Commercial Products) | -55 C | 125 °C | Brass | Thermoplastic Glass Filled | 300 VDC | Black | Gold | UL94 V-0 | Receptacle Female Sockets | Housing/Shell (Unthreaded) | 7.5 A | 0.203 çm | 8 µin | Solder | 2 | Through Hole | D-Sub | B DB | 3 | 25 | Signal | ||||
Amphenol ICC (Commercial Products) | -55 C | 125 °C | Brass | Thermoplastic Glass Filled | 300 VDC | Black | Gold | UL94 V-0 | Receptacle Female Sockets | Housing/Shell (Unthreaded) | 7.5 A | 0.76 Ám | 30 Áin | 2 | Free Hanging (In-Line) | D-Sub | B DB | 3 | 25 | Signal | |||||
 Amphenol ICC (Commercial Products) | -55 C | 125 °C | Brass | Thermoplastic Glass Filled | 300 VDC | Black | Gold | UL94 V-0 | Receptacle Female Sockets | Housing/Shell (Unthreaded) | 7.5 A | 0.203 çm | 8 µin | Solder | 2 | Through Hole | D-Sub | B DB | 3 | 25 | Signal | ||||
Amphenol ICC (Commercial Products) | -55 C | 125 °C | Brass | Thermoplastic Glass Filled | 300 VDC | Black | Gold | UL94 V-0 | 10.3 mm | 0.406 in | Mounting Brackets | Receptacle Female Sockets | Housing/Shell (Unthreaded) | 7.5 A | 0.203 çm | 8 µin | Solder | 2 | Right Angle Through Hole | D-Sub | B DB | 3 | 25 | Signal | |
Amphenol ICC (Commercial Products) | -55 C | 125 °C | Brass | Thermoplastic Glass Filled | 300 VDC | Black | Gold | UL94 V-0 | 14.99 mm | 0.59 in | Board Lock Mounting Brackets | Receptacle Female Sockets | Housing/Shell (Unthreaded) | 7.5 A | 0.203 çm | 8 µin | Solder | 2 | Right Angle Through Hole | D-Sub | B DB | 3 | 25 | Signal |
