837-027 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 27POS 0.156
| Part | Termination Rows | Material - Insulation | Contact Material | Gender | Contact Finish | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Read Out | Contact Type | Pitch | Pitch | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Number of Positions/Bay/Row |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Female | Gold | Green | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Wire Wrap | Single | Cantilever | 3.96 mm | 0.156 in | Through Hole | 0.25 Ám | 10 Áin | 1 | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | 27 |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Female | Gold | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Single | Cantilever | 3.96 mm | 0.156 in | Right Angle Through Hole | 0.25 Ám | 10 Áin | 1 | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | 27 |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Female | Gold | Green | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Solder | Single | Cantilever | 3.96 mm | 0.156 in | Through Hole | 0.25 Ám | 10 Áin | 1 | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | 27 |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Female | Gold | Green | 0.156 " | 3.96 mm | Wire Wrap | Single | Cantilever | 3.96 mm | 0.156 in | Through Hole | 0.25 Ám | 10 Áin | 1 | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | 27 | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Female | Gold | Green | 4-40 Flush Mount Threaded Insert Top Opening | Wire Wrap | Single | Cantilever | 3.96 mm | 0.156 in | Through Hole | 0.25 Ám | 10 Áin | 1 | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | 27 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Female | Gold | Green | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Single | Cantilever | 3.96 mm | 0.156 in | Right Angle Through Hole | 0.25 Ám | 10 Áin | 1 | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | 27 |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Female | Gold | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Single | Cantilever | 3.96 mm | 0.156 in | Right Angle Through Hole | 0.25 Ám | 10 Áin | 1 | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | 27 |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Female | Gold | Green | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Solder | Single | Cantilever | 3.96 mm | 0.156 in | Through Hole | 0.25 Ám | 10 Áin | 1 | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | 27 |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Female | Gold | Green | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Wire Wrap | Single | Cantilever | 3.96 mm | 0.156 in | Through Hole | 0.25 Ám | 10 Áin | 1 | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | 27 |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Female | Gold | Green | Flush Mount M3 Threaded Insert Top Opening | Solder | Single | Cantilever | 3.96 mm | 0.156 in | Through Hole | 0.25 Ám | 10 Áin | 1 | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | 27 |
