PRPC006 Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN HEADER R/A 12POS 2.54MM
| Part | Shrouding | Contact Length - Mating | Contact Length - Mating | Number of Positions Loaded | Contact Finish - Mating | Insulation Color | Termination | Contact Finish - Post | Insulation Height | Insulation Height | Style | Contact Type | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Current Rating (Amps) | Insulation Material | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Pitch - Mating | Pitch - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Post | Mounting Type | Contact Length - Post | Contact Length - Post | Number of Rows [custom] | Connector Type | Contact Shape | Fastening Type | Material Flammability Rating | Contact Material | Number of Rows | Overall Contact Length | Overall Contact Length | Overall Contact Length | Overall Contact Length [x] | Overall Contact Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | Unshrouded | 8.08 mm | 0.318 in | All | Gold | Black | Solder | Gold | 0.197 " | 5 mm | Board to Board Cable | Male Pin | 0.1 in | 2.54 mm | 3 A | Polybutylene Terephthalate (PBT) | 12 | -40 C | 105 ░C | 0.1 " | 2.54 mm | Flash | Flash | Right Angle Through Hole | 3.05 mm | 0.12 in | 2 | Header Breakaway | Square | Push-Pull | UL94 V-0 | Brass | ||||||
 Sullins Connector Solutions | Unshrouded | 5.84 mm | 0.23 in | All | Gold | Black | Solder | Gold | 0.098 " | 2.5 mm | Board to Board Cable | Male Pin | 3 A | Polybutylene Terephthalate (PBT) | 6 | -40 C | 105 ░C | 0.1 " | 2.54 mm | Flash | Flash | Through Hole | 3.05 mm | 0.12 in | Header Breakaway | Square | Push-Pull | UL94 V-0 | Brass | 1 | 0.448 in | 11.39 mm | ||||||
 Sullins Connector Solutions | Unshrouded | 8.08 mm | 0.318 in | All | Gold | Black | Solder | Gold | 0.098 " | 2.5 mm | Board to Board Cable | Male Pin | 0.1 in | 2.54 mm | 3 A | Polybutylene Terephthalate (PBT) | 12 | -40 C | 105 ░C | 0.1 " | 2.54 mm | Flash | Flash | Through Hole | 5.58 mm | 0.22 in | 2 | Header Breakaway | Square | Push-Pull | UL94 V-0 | Brass | 0.637 in | 16.17 mm | ||||
 Sullins Connector Solutions | Unshrouded | 5.84 mm | 0.23 in | All | Gold | Black | Solder | Gold | 0.098 " | 2.5 mm | Board to Board Cable | Male Pin | 3 A | Polybutylene Terephthalate (PBT) | 6 | -40 C | 105 ░C | 0.1 " | 2.54 mm | Flash | Flash | Right Angle Through Hole | 3.05 mm | 0.12 in | Header Breakaway | Square | Push-Pull | UL94 V-0 | Brass | 1 | ||||||||
 Sullins Connector Solutions | Unshrouded | 5.84 mm | 0.23 in | All | Gold | Black | Solder | Gold | 0.098 " | 2.5 mm | Board to Board Cable | Male Pin | 0.1 in | 2.54 mm | 3 A | Polybutylene Terephthalate (PBT) | 12 | -40 C | 105 ░C | 0.1 " | 2.54 mm | Flash | Flash | Through Hole | 5.84 mm | 0.23 " | 2 | Header Breakaway | Square | Push-Pull | UL94 V-0 | Brass | 0.558 in | 14.18 mm | ||||
 Sullins Connector Solutions | Unshrouded | 5.84 mm | 0.23 in | All | Gold | Black | Solder | Gold | 0.098 " | 2.5 mm | Board to Board Cable | Male Pin | 3 A | Polybutylene Terephthalate (PBT) | 6 | -40 C | 105 ░C | 0.1 " | 2.54 mm | Flash | Flash | Through Hole | 8.13 mm | 0.32 in | Header Breakaway | Square | Push-Pull | UL94 V-0 | Brass | 1 | 0.648 in | 16.47 mm | ||||||
 Sullins Connector Solutions | Unshrouded | 5.84 mm | 0.23 in | All | Gold | Black | Solder | Gold | 0.098 " | 2.5 mm | Board to Board Cable | Male Pin | 3 A | Polybutylene Terephthalate (PBT) | 6 | -40 C | 105 ░C | 0.1 " | 2.54 mm | Flash | Flash | Through Hole | 10.67 mm | 0.42 in | Header Breakaway | Square | Push-Pull | UL94 V-0 | Brass | 1 | 0.748 in | 19.01 mm | ||||||
 Sullins Connector Solutions | Unshrouded | 5.84 mm | 0.23 in | All | Gold | Black | Solder | Gold | 0.098 " | 2.5 mm | Board to Board Cable | Male Pin | 3 A | Polybutylene Terephthalate (PBT) | 6 | -40 C | 105 ░C | 0.1 " | 2.54 mm | Flash | Flash | Right Angle Through Hole | 8.13 mm | 0.32 in | Header Breakaway | Square | Push-Pull | UL94 V-0 | Brass | 1 | ||||||||
 Sullins Connector Solutions | Unshrouded | 8.08 mm | 0.318 in | All | Gold | Black | Solder | Gold | 0.098 " | 2.5 mm | Board to Board Cable | Male Pin | 3 A | Polybutylene Terephthalate (PBT) | 6 | -40 C | 105 ░C | 0.1 " | 2.54 mm | Flash | Flash | Right Angle Through Hole | 3.05 mm | 0.12 in | Header Breakaway | Square | Push-Pull | UL94 V-0 | Brass | 1 | ||||||||
 Sullins Connector Solutions | Unshrouded | 8.08 mm | 0.318 in | All | Gold | Black | Solder | Gold | 0.098 " | 2.5 mm | Board to Board Cable | Male Pin | 0.1 in | 2.54 mm | 3 A | Polybutylene Terephthalate (PBT) | 12 | -40 C | 105 ░C | 0.1 " | 2.54 mm | Flash | Flash | Through Hole | 3.05 mm | 0.12 in | 2 | Header Breakaway | Square | Push-Pull | UL94 V-0 | Brass | 0.537 in | 13.63 mm |
