SI8261 Series

Catalog

GATE DRIVERS 3.75 KV OPTO-DRIVER REPLACEMENT IN PDIP8

Part	Qualification	Technology	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Current - Peak Output	Operating Temperature [Max]	Operating Temperature [Min]	Current - DC Forward (If) (Max) [Max]	Mounting Type	Voltage - Isolation	Grade	Common Mode Transient Immunity (Min) [Min]	Voltage - Forward (Vf) (Typ)	Approval Agency	Propagation Delay tpLH / tpHL (Max) [Max] [y]	Propagation Delay tpLH / tpHL (Max) [Max] [x]	Pulse Width Distortion (Max) [Max]	Number of Channels [custom]	Supplier Device Package	Pulse Width Distortion (Max)	Voltage - Output Supply [Max]	Voltage - Output Supply [Min]	Package / Case	Package / Case	Package / Case
Skyworks Solutions Inc. SI8261BAC-C-IP	AEC-Q100	Capacitive Coupling	1.2 A	500 mA	4 A	125 °C	-40 C	30 mA	Surface Mount	3750 Vrms	Automotive	35 kV/µs	2.8 V	CQC CSA UR VDE	50 ns	60 ns	28 ns	1	8-DIP Gull Wing
Skyworks Solutions Inc. SI8261ACA-C-ISR	AEC-Q100	Capacitive Coupling	1.2 A	500 mA	600 mA	125 °C	-40 C	30 mA	Surface Mount		Automotive	35 kV/µs	2.8 V	CQC CSA UR VDE	50 ns	60 ns		1		10 ns	30 V	13.5 V
Skyworks Solutions Inc. SI8261ACC-C-IP	AEC-Q100	Capacitive Coupling	600 mA	400 mA	600 mA	125 °C	-40 C	30 mA	Surface Mount	3750 Vrms	Automotive	35 kV/µs	2.8 V	CQC CSA UR VDE	50 ns	60 ns	28 ns	1	8-DIP Gull Wing		30 V	13.5 V
Skyworks Solutions Inc. SI8261BBC-C-IP	AEC-Q100	Capacitive Coupling	1.2 A	500 mA	4 A	125 °C	-40 C	30 mA	Surface Mount	3750 Vrms	Automotive	35 kV/µs	2.8 V	CQC CSA UR VDE	50 ns	60 ns	28 ns	1	8-DIP Gull Wing
Skyworks Solutions Inc. SI8261BCD-C-IS	AEC-Q100	Capacitive Coupling	1.2 A	500 mA	4 A	125 °C	-40 C	30 mA	Surface Mount		Automotive	35 kV/µs	2.8 V	CQC CSA UR VDE	50 ns	60 ns	28 ns	1	6-SDIP Gull Wing		30 V	13.5 V	6-SOIC (0.295" 7.50mm Width)
Skyworks Solutions Inc. SI8261BAC-C-IPR	AEC-Q100	Capacitive Coupling	1.2 A	500 mA	4 A	125 °C	-40 C	30 mA	Surface Mount	3750 Vrms	Automotive	35 kV/µs	2.8 V	CQC CSA UR VDE	50 ns	60 ns	28 ns	1	8-DIP Gull Wing
Skyworks Solutions Inc. SI8261BAD-C-IS	AEC-Q100	Capacitive Coupling	1.2 A	500 mA	4 A	125 °C	-40 C	30 mA	Surface Mount		Automotive	35 kV/µs	2.8 V	CQC CSA UR VDE	50 ns	60 ns	28 ns	1	6-SDIP Gull Wing				6-SOIC (0.295" 7.50mm Width)
Skyworks Solutions Inc. SI8261AAC-C-IS	AEC-Q100	Capacitive Coupling	600 mA	400 mA	600 mA	125 °C	-40 C	30 mA	Surface Mount	3750 Vrms	Automotive	35 kV/µs	2.8 V	CQC CSA UR VDE	50 ns	60 ns	28 ns	1	8-SOIC				8-SOIC	0.154 in	3.9 mm
Skyworks Solutions Inc. SI8261BBA-C-IS	AEC-Q100	Capacitive Coupling	1.2 A	500 mA	4 A	125 °C	-40 C	30 mA			Automotive	35 kV/µs	2.8 V	CQC CSA UR VDE	50 ns	60 ns		1		10 ns
Skyworks Solutions Inc. SI8261ACC-C-IPR	AEC-Q100	Capacitive Coupling	600 mA	400 mA	600 mA	125 °C	-40 C	30 mA	Surface Mount	3750 Vrms	Automotive	35 kV/µs	2.8 V	CQC CSA UR VDE	50 ns	60 ns	28 ns	1	8-DIP Gull Wing		30 V	13.5 V
