LCB3 Series

Catalog

CONN TERM RECT TONG 3/0 AWG #1/2

Part	Terminal Type	Tab Thickness	Tab Thickness	Termination	Stud/Tab Size	Mounting Type	Terminal Style	Diameter - Barrel ID [diameter]	Diameter - Barrel ID [diameter]	Contact Material	Diameter - Barrel OD [diameter]	Diameter - Barrel OD [diameter]	Insulation	Diameter - Ring ID [diameter]	Diameter - Ring ID [diameter]	Contact Finish	Width - Outer Edges [y]	Width - Outer Edges [y]	Diameter - Ring ID [diameter]	Length - Overall [x]	Length - Overall [x]
Panduit Corp LCB3/0-12H-X	Rectangular Tongue	0.13 in	3.3 mm	Barrel Crimp	1/2 Stud	45° Angle Free Hanging (In-Line)	Single Stud Hole	0.51 in	12.95 mm	Copper	16.26 mm	0.64 "	Non-Insulated	0.53 in	13.46 mm	Electro-Tin	24.38 mm	0.96 in
Panduit Corp LCB3/0-38-X	Rectangular Tongue	0.13 in	3.3 mm	Barrel Crimp	3/8 Stud	Free Hanging (In-Line)	Single Stud Hole	0.51 in	12.95 mm	Copper	16.26 mm	0.64 "	Non-Insulated	10.41 mm		Electro-Tin	24.38 mm	0.96 in	0.41 "	2.87 in	72.9 mm
Panduit Corp LCB3/0-12-X	Rectangular Tongue	0.13 in	3.3 mm	Barrel Crimp	1/2 Stud	Free Hanging (In-Line)	Single Stud Hole	0.51 in	12.95 mm	Copper	16.26 mm	0.64 "	Non-Insulated	0.53 in	13.46 mm	Electro-Tin	24.38 mm	0.96 in		3.12 in	79.25 mm
