845-021 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 21POS 0.100
| Part | Termination Rows | Material - Insulation | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Color | Gender | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row [custom] | Mounting Type | Contact Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Card Type | Termination | Read Out | Contact Finish | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | 125 °C | -40 C | Green | Female | 1 | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Through Hole | Cantilever | 21 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Non Specified - Single Edge | Wire Wrap | Single | Gold | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | 125 °C | -40 C | Green | Female | 1 | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Through Hole | Cantilever | 21 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | Single | Gold | Side Mount Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | 125 °C | -40 C | Green | Female | 1 | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Through Hole | Cantilever | 21 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Non Specified - Single Edge | Wire Wrap | Single | Gold | Floating Bobbin Flush Mount |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | 125 °C | -40 C | Green | Female | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Through Hole | Cantilever | 21 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | Single | Gold | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | 125 °C | -40 C | Green | Female | 1 | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Right Angle Through Hole | Cantilever | 21 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | Single | Gold | Side Mount Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | 125 °C | -40 C | Green | Female | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Through Hole | Cantilever | 21 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | Single | Gold | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | 125 °C | -40 C | Green | Female | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Through Hole | Cantilever | 21 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Non Specified - Single Edge | Wire Wrap | Single | Gold | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | 125 °C | -40 C | Green | Female | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Through Hole | Cantilever | 21 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder Eyelet(s) | Single | Gold | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | 125 °C | -40 C | Green | Female | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Through Hole | Cantilever | 21 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | Single | Gold | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | 125 °C | -40 C | Green | Female | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Through Hole | Cantilever | 21 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | Single | Gold | M3 Threaded Insert Top Mount Opening |
