PAB.M0 Series
Manufacturer: LEMO
Beta
⌘K
CONN PLUG MALE 5P GOLD SLDR CUP
| Part | Color | Shell Size - Insert | Contact Finish - Mating | Current Rating (Amps) | Features | Cable Opening [Min] [custom] | Cable Opening [Max] [custom] | Cable Opening [Min] [custom] | Cable Opening [Max] [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Fastening Type | Insert Material | Primary Material | Shielding | Backshell Material, Plating | Mounting Type | Orientation | Applications | Connector Type | Shell Material | Ingress Protection | Number of Positions | Cable Opening [Min] [diameter] | Cable Opening [Max] [diameter] | Cable Opening [Max] [diameter] | Cable Opening [Min] [diameter] | Cable Opening [custom] | Cable Opening [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LEMO | Gray Red | M05 | Gold | 7 A | Backshell | 0.157 in | 0.205 in | 4 mm | 5.2 mm | 150 °C | -50 °C | Detent Lock Push-Pull | Polyetheretherketone (PEEK) | Plastic | Unshielded | Polysulfone (PSU) | Free Hanging (In-Line) | B | Automotive Industrial Medical Testing Equipment & Measurement | Male Pins Plug | Polysulfone (PSU) | IP50 | |||||||
LEMO | Blue Gray | M04 | Gold | 8 A | Backshell | 150 °C | -50 °C | Detent Lock Push-Pull | Polyetheretherketone (PEEK) | Plastic | Unshielded | Polysulfone (PSU) | Free Hanging (In-Line) | B | Automotive Industrial Medical Testing Equipment & Measurement | Male Pins Plug | Polysulfone (PSU) | IP50 | 4 | 2.7 mm | 0.154 in | 3.9 mm | 0.106 in | ||||||
LEMO | Gray Yellow | M05 | Gold | 7 A | Backshell | 150 °C | -50 °C | Detent Lock Push-Pull | Polyetheretherketone (PEEK) | Plastic | Unshielded | Polysulfone (PSU) | Free Hanging (In-Line) | B | Automotive Industrial Medical Testing Equipment & Measurement | Male Pins Plug | Polysulfone (PSU) | IP50 | 0.209 in 0.256 in | 5.3 mm 6.5 mm | |||||||||
Gray Yellow | M08 | Gold | 5 A | Backshell | 150 °C | -50 °C | Detent Lock Push-Pull | Polyetheretherketone (PEEK) | Plastic | Unshielded | Polysulfone (PSU) | Free Hanging (In-Line) | B | Automotive Industrial Medical Testing Equipment & Measurement | Male Pins Plug | Polysulfone (PSU) | IP50 | 8 | 2.7 mm | 0.154 in | 3.9 mm | 0.106 in | |||||||
LEMO | Gray Green | M04 | Gold | 8 A | Backshell | 150 °C | -50 °C | Detent Lock Push-Pull | Polyetheretherketone (PEEK) | Plastic | Unshielded | Polysulfone (PSU) | Free Hanging (In-Line) | B | Automotive Industrial Medical Testing Equipment & Measurement | Male Pins Plug | Polysulfone (PSU) | IP50 | 4 | 2.7 mm | 0.154 in | 3.9 mm | 0.106 in | ||||||
LEMO | Gray Green | M09 | Gold | 3 A | Backshell | 0.157 in | 0.205 in | 4 mm | 5.2 mm | 150 °C | -50 °C | Detent Lock Push-Pull | Polyetheretherketone (PEEK) | Plastic | Unshielded | Polysulfone (PSU) | Free Hanging (In-Line) | B | Automotive Industrial Medical Testing Equipment & Measurement | Male Pins Plug | Polysulfone (PSU) | IP50 | 9 | ||||||
LEMO | Blue Gray | M04 | Gold | 8 A | Backshell | 0.157 in | 0.205 in | 4 mm | 5.2 mm | 150 °C | -50 °C | Detent Lock Push-Pull | Polyetheretherketone (PEEK) | Plastic | Unshielded | Polysulfone (PSU) | Free Hanging (In-Line) | B | Automotive Industrial Medical Testing Equipment & Measurement | Male Pins Plug | Polysulfone (PSU) | IP50 | 4 | ||||||
LEMO | Black | M04 | Gold | 8 A | Backshell | 170 °C | -50 °C | Detent Lock Push-Pull | Polyetheretherketone (PEEK) | Plastic | Unshielded | Polyetherimide (PEI) | Free Hanging (In-Line) | B | Automotive Industrial Medical Testing Equipment & Measurement | Male Pins Plug | Polyetherimide (PEI) | IP50 | 4 | 2.7 mm | 0.154 in | 3.9 mm | 0.106 in | ||||||
LEMO | Blue Gray | M09 | Gold | 3 A | Backshell | 0.157 in | 0.205 in | 4 mm | 5.2 mm | 150 °C | -50 °C | Detent Lock Push-Pull | Polyetheretherketone (PEEK) | Plastic | Unshielded | Polysulfone (PSU) | Free Hanging (In-Line) | B | Automotive Industrial Medical Testing Equipment & Measurement | Male Pins Plug | Polysulfone (PSU) | IP50 | 9 | ||||||
LEMO | Gray | M04 | Gold | 8 A | Backshell | 150 °C | -50 °C | Detent Lock Push-Pull | Polyetheretherketone (PEEK) | Plastic | Unshielded | Polysulfone (PSU) | Free Hanging (In-Line) | B | Automotive Industrial Medical Testing Equipment & Measurement | Male Pins Plug | Polysulfone (PSU) | IP50 | 4 | 2.7 mm | 0.154 in | 3.9 mm | 0.106 in |
