J01440A0 Series
Manufacturer: Telegartner Inc
Beta
⌘K
4.3-10 PLG STR CR/CR S G1
| Part | Body Finish | Operating Temperature (Min) | Operating Temperature (Max) | Body Material | Mating Cycles | Dielectric Material | Center Contact Plating | Housing Color | Contact Termination | Connector Style | Center Contact Material | Impedance | Fastening Type | Number of Ports | Mounting Type | Shield Termination | Connector Type | Frequency - Max | Ingress Protection Description | Ingress Protection IP Rating | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Telegartner Inc | White Bronze | -40 °C | 85 °C | Brass | 100 cycles | Polytetrafluoroethylene (PTFE) | Silver | Silver | Crimp | 4.3/10 | Brass | 50 Ohm | Threaded | 1 | Free Hanging (In-Line) | Crimp | Male Pin Plug | 6000 MHz | |||
 Telegartner Inc | White Bronze | -40 °C | 85 °C | Brass | 100 cycles | Polytetrafluoroethylene (PTFE) | Silver | Silver | Solder | 4.3/10 | Brass | 50 Ohm | Threaded | 1 | Free Hanging (In-Line) Right Angle | Crimp | Male Pin Plug | 6000 MHz | Dust Tight Waterproof | IP67 | |
 Telegartner Inc | White Bronze | -40 °C | 85 °C | Brass | 100 cycles | Silver | Silver | Crimp Solder | 4.3/10 | Copper Alloy | 50 Ohm | Threaded | 1 | Free Hanging (In-Line) | Clamp | Male Pin Plug | 6000 MHz | Dust Tight Waterproof | IP68 | 1000 V | |
 Telegartner Inc | White Bronze | -40 °C | 85 °C | Brass | 100 cycles | Polytetrafluoroethylene (PTFE) | Silver | Silver | Crimp | 4.3/10 | Brass | 50 Ohm | Threaded | 1 | Free Hanging (In-Line) | Crimp | Male Pin Plug | 6000 MHz | |||
 Telegartner Inc | Silver | -55 °C | 155 °C | Brass | 100 cycles | Polytetrafluoroethylene (PTFE) | Silver | Silver | Solder | 4.3/10 | Brass | 50 Ohm | Threaded | 1 | Free Hanging (In-Line) | Solder | Male Pin Plug | 6000 MHz | Dust Tight Waterproof | IP67 | |
Telegartner Inc | Silver | -55 °C | 155 °C | Brass | 100 cycles | Polytetrafluoroethylene (PTFE) | Silver | Silver | Solder | 4.3/10 | Brass | 50 Ohm | Threaded | 1 | Free Hanging (In-Line) | Solder | Male Pin Plug | 6000 MHz | Dust Tight Waterproof | IP67 | |
 Telegartner Inc | White Bronze | -40 °C | 85 °C | Brass | 500 cycles | Polyethylene (PE) | Silver | Silver | Crimp Solder | 4.3/10 | Copper Alloy | 50 Ohm | Threaded | 1 | Free Hanging (In-Line) | Clamp | Male Pin Plug | 6000 MHz | Dust Tight Waterproof | IP68 | 1000 V |
Telegartner Inc | White Bronze | -40 °C | 85 °C | Brass | 100 cycles | Polytetrafluoroethylene (PTFE) | Silver | Silver | Crimp | 4.3/10 | Copper Alloy | 50 Ohm | Threaded | 1 | Free Hanging (In-Line) | Crimp | Male Pin Plug | 6000 MHz | |||
 Telegartner Inc | White Bronze | -40 °C | 85 °C | Brass | 100 cycles | Polytetrafluoroethylene (PTFE) | Silver | Silver | Crimp Solder | 4.3/10 | Copper Alloy | 50 Ohm | Threaded | 1 | Free Hanging (In-Line) Right Angle | Clamp | Male Pin Plug | 6000 MHz | Dust Tight Waterproof | IP68 | 1000 V |
 Telegartner Inc | White Bronze | -40 °C | 85 °C | Brass | 100 cycles | Polytetrafluoroethylene (PTFE) | Silver | Silver | Crimp Solder | 4.3/10 | Copper Alloy | 50 Ohm | Threaded | 1 | Free Hanging (In-Line) Right Angle | Clamp | Male Pin Plug | 6000 MHz | Dust Tight Waterproof | IP68 | 1000 V |
