LFC600602C Series

600V CLASS CD BLOCK 60A 2 POLE NON-ID

Catalog

600V CLASS CD BLOCK 60A 2 POLE NON-ID

Part	Orientation	Fuse Size [x]	Fuse Size [diameter]	Fuse Size [diameter]	Fuse Size [x]	Termination Style	Fuseholder Type	For Use With/Related Products	Current Rating (Amps)	Voltage	Number of Circuits	Fuse Type	Mounting Type	Contact Material
Littelfuse/Commercial Vehicle Products LFC600602C	Horizontal	1.88 "	0.85 "	21.6 mm	47.8 mm	Box Lug	Holder	Class CC/CD Fuses	60 A	600 V	2	Cartridge	DIN Rail	Copper Alloy

600V CLASS CD BLOCK 60A 2 POLE NON-ID

• DIN Rail (snap-to-release) mountable optional

• Universal mounting holes make for easy replacement

• Rejection feature that prevents the insertion of fuses with lower interrupting rating or voltage ratings

• Clip design reduces resistance and heat

• Non DIN Rail fuseblocks have interlocking feature allowing ganging to produce a fuseblock with any number of poles

• Covers available for most amperages
