DML-04 Series

Manufacturer: Adam Tech

Catalog

CONN HEADER VERT 4POS 3MM

Part	Contact Length - Post [x]	Contact Length - Post [x]	Connector Type	Material Flammability Rating	Contact Shape	Row Spacing - Mating	Row Spacing - Mating	Features	Style	Number of Positions Loaded	Pitch - Mating	Pitch - Mating	Contact Type	Contact Material	Number of Rows [custom]	Voltage Rating	Mounting Type	Current Rating (Amps)	Shrouding	Fastening Type	Insulation Color	Number of Positions	Insulation Material	Contact Finish - Post	Termination	Insulation Height [z]	Insulation Height [z]	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]
Adam Tech DML-04-A-V-T-A-BL	0.126 "	3.2 mm	Header	UL94 V-0	Square	0.118 in	3 mm	Board Lock	Board to Cable/Wire	All	3 mm	0.118 in	Male Pin	Brass	2	250 VAC	Through Hole	Varies by Wire Gauge	Shrouded - 4 Wall	Locking Ramp	Black	4	Thermoplastic	Tin	Kinked Pin Solder	0.39 in	9.91 mm
Adam Tech DML-04-A-V-T-TSMT-PP-T/R			Header	UL94 V-0	Square	0.118 in	3 mm	Solder Retention	Board to Cable/Wire	All	3 mm	0.118 in	Male Pin	Brass	2	250 VAC	Surface Mount		Shrouded - 4 Wall	Locking Ramp	Black	4	Thermoplastic	Tin	Solder	0.39 in	9.91 mm	5 A	105 ░C	-25 °C
