87037 Series

Catalog

CONN HEADER VERT 12POS 2.54MM

Part	Contact Type	Number of Positions Loaded	Material Flammability Rating	Contact Material	Contact Finish - Mating	Insulation Height	Insulation Height	Contact Shape	Number of Rows	Shrouding	Number of Positions	Connector Type	Insulation Color	Pitch - Mating	Pitch - Mating	Contact Length - Post [x]	Contact Length - Post [x]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Fastening Type	Mounting Type	Overall Contact Length	Overall Contact Length	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Termination
Amphenol ICC (FCI) 87037-112HLF	Male Pin	All	UL94 V-0	Phosphor Bronze	Gold or Gold GXT™	0.1 in	2.54 mm	Square	2	Unshrouded	12	Header	Black	0.1 in	2.54 mm	0.12 in	3.05 mm	30 Áin	0.76 Ám	Push-Pull	Through Hole	1.24 in	31.5 mm	2.54 mm	0.1 in	Solder
Amphenol ICC (FCI) 87037-272H	Male Pin	All	UL94 V-0	Phosphor Bronze	Gold or Gold GXT™	0.1 in	2.54 mm	Square	2	Unshrouded	72	Header	Black	0.1 in	2.54 mm	0.12 in	3.05 mm	15 µin	0.38 µm	Push-Pull	Through Hole	1.24 in	31.5 mm	2.54 mm	0.1 in	Solder
Amphenol ICC (FCI) 87037-172H	Male Pin	All	UL94 V-0	Phosphor Bronze	Gold or Gold GXT™	0.1 in	2.54 mm	Square	2	Unshrouded	72	Header	Black	0.1 in	2.54 mm	0.12 in	3.05 mm	30 Áin	0.76 Ám	Push-Pull	Through Hole	1.24 in	31.5 mm	2.54 mm	0.1 in	Solder
