1445089 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CONN HEADER R/A 9POS 3MM

Part	Applications	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Type	Contact Length - Post	Contact Length - Post	Current Rating (Amps)	Number of Rows	Shrouding	Pitch - Mating	Pitch - Mating	Voltage Rating	Contact Finish - Mating	Insulation Color	Operating Temperature [Min]	Operating Temperature [Max]	Features	Number of Positions	Contact Finish - Post	Number of Positions Loaded	Material Flammability Rating	Termination	Insulation Height [custom]	Insulation Height [custom]	Connector Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Material	Style	Mounting Type	Insulation Material	Fastening Type	Contact Shape
TE Connectivity AMP Connectors 1445089-9	General Purpose	2.54 µm	100 µin	Male Pin	0.138 in	3.5 mm	Varies by Wire Gauge	1	Shrouded - 4 Wall	3 mm	0.118 in	250 V	Gold	Black	-40 C	105 ░C	Board Lock	9	Tin-Lead	All	UL94 V-0	Solder	0.152 in	3.85 mm	Header	0.38 µm	15 µin	Brass	Board to Cable/Wire	Right Angle Through Hole	Nylon Polyamide (PA)	Locking Ramp	Square
TE Connectivity AMP Connectors 3-1445089-1	General Purpose	2.54 µm	100 µin	Male Pin	0.138 in	3.5 mm	Varies by Wire Gauge	1	Shrouded - 4 Wall	3 mm	0.118 in	250 V	Gold	Black	-40 C	105 ░C	Board Lock	11	Tin	All	UL94 V-0	Solder	0.152 in	3.85 mm	Header	0.38 µm	15 µin	Brass	Board to Cable/Wire	Right Angle Through Hole	Nylon Polyamide (PA)	Locking Ramp	Square
TE Connectivity AMP Connectors 1445089-5	General Purpose	2.54 µm	100 µin	Male Pin	0.138 in	3.5 mm	Varies by Wire Gauge	1	Shrouded - 4 Wall	3 mm	0.118 in	250 V	Gold	Black	-40 C	105 ░C	Board Lock	5	Tin-Lead	All	UL94 V-0	Solder	0.152 in	3.85 mm	Header	0.38 µm	15 µin	Brass	Board to Cable/Wire	Right Angle Through Hole	Nylon Polyamide (PA)	Locking Ramp	Square
TE Connectivity AMP Connectors 2-1445089-9	General Purpose	2.54 µm	100 µin	Male Pin	0.138 in	3.5 mm	Varies by Wire Gauge	1	Shrouded - 4 Wall	3 mm	0.118 in	250 V	Gold	Black	-40 C	105 ░C	Board Lock	9	Tin	All	UL94 V-0	Solder	0.152 in	3.85 mm	Header	0.38 µm	15 µin	Brass	Board to Cable/Wire	Right Angle Through Hole	Nylon Polyamide (PA)	Locking Ramp	Square
TE Connectivity AMP Connectors 1-1445089-1	General Purpose	2.54 µm	100 µin	Male Pin	0.138 in	3.5 mm	Varies by Wire Gauge	1	Shrouded - 4 Wall	3 mm	0.118 in	250 V	Gold	Black	-40 C	105 ░C	Board Lock	11	Tin-Lead	All	UL94 V-0	Solder	0.152 in	3.85 mm	Header	0.38 µm	15 µin	Brass	Board to Cable/Wire	Right Angle Through Hole	Nylon Polyamide (PA)	Locking Ramp	Square
TE Connectivity AMP Connectors 3-1445089-2	General Purpose	2.54 µm	100 µin	Male Pin	0.138 in	3.5 mm	Varies by Wire Gauge	1	Shrouded - 4 Wall	3 mm	0.118 in	250 V	Gold	Black	-40 C	105 ░C	Board Lock	12	Tin	All	UL94 V-0	Solder	0.152 in	3.85 mm	Header	0.38 µm	15 µin	Brass	Board to Cable/Wire	Right Angle Through Hole	Nylon Polyamide (PA)	Locking Ramp	Square
TE Connectivity AMP Connectors 1-1445089-2	General Purpose	2.54 µm	100 µin	Male Pin	0.138 in	3.5 mm	Varies by Wire Gauge	1	Shrouded - 4 Wall	3 mm	0.118 in	250 V	Gold	Black	-40 C	105 ░C	Board Lock	12	Tin-Lead	All	UL94 V-0	Solder	0.152 in	3.85 mm	Header	0.38 µm	15 µin	Brass	Board to Cable/Wire	Right Angle Through Hole	Nylon Polyamide (PA)	Locking Ramp	Square
