634-M62 Series
Manufacturer: EDAC Inc.
Beta
⌘K
634M SERIES RIGHT ANGLE D-SUB
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Material | Contact Finish Thickness | Termination | Connector Type | Connector Style | Backset Spacing | Backset Spacing | Current Rating (Amps) | Contact Type | Flange Feature | Contact Finish | Number of Rows [custom] | Features | Shell Size, Connector Layout | Shell Size, Connector Layout | Shell Material, Finish | Number of Positions | Mounting Type | Material Flammability Rating | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | Flash | Solder | Receptacle Female Sockets | D-Sub High Density | 8.89 mm | 0.35 in | 5 A | Signal | 4-40 | Gold | 3 | Mounting Brackets Shielded | C DC | 4 | Nickel Plated Steel | 62 | Board Edge Right Angle Through Hole | UL94 V-0 | |||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | White | Copper Alloy | Solder | Receptacle Female Sockets | D-Sub High Density | 8.89 mm | 0.35 in | 5 A | Signal | Housing/Shell (Unthreaded) | Gold | 3 | Shielded | C DC | 4 | Nickel Plated Steel | 62 | Board Edge Right Angle Through Hole | UL94 V-0 | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | Solder | Receptacle Female Sockets | D-Sub High Density | 8.89 mm | 0.35 in | 5 A | Signal | Housing/Shell (Unthreaded) | Gold | 3 | Shielded | C DC | 4 | 62 | Board Edge Right Angle Through Hole | UL94 V-0 | 15 µin | 0.38 µm | |||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | White | Copper Alloy | Flash | Solder | Receptacle Female Sockets | D-Sub High Density | 8.89 mm | 0.35 in | 5 A | Signal | 4-40 | Gold | 3 | Mounting Brackets Shielded | C DC | 4 | 62 | Board Edge Right Angle Through Hole | UL94 V-0 | ||||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | Flash | Solder | Receptacle Female Sockets | D-Sub High Density | 8.89 mm | 0.35 in | 5 A | Signal | 4-40 | Gold | 3 | Board Lock Mounting Brackets Shielded | C DC | 4 | 62 | Board Edge Right Angle Through Hole | UL94 V-0 | ||||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | Solder | Receptacle Female Sockets | D-Sub High Density | 8.89 mm | 0.35 in | 5 A | Signal | Housing/Shell | Gold | 3 | Board Lock Mounting Brackets Shielded | C DC | 4 | 62 | Board Edge Right Angle Through Hole | UL94 V-0 | 15 µin | 0.38 µm | 4-40 | ||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | White | Copper Alloy | Flash | Solder | Receptacle Female Sockets | D-Sub High Density | 8.89 mm | 0.35 in | 5 A | Signal | 4-40 | Gold | 3 | Board Lock Mounting Brackets Shielded | C DC | 4 | Nickel Plated Steel | 62 | Board Edge Right Angle Through Hole | UL94 V-0 | |||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | Solder | Receptacle Female Sockets | D-Sub High Density | 8.89 mm | 0.35 in | 5 A | Signal | Housing/Shell | Gold | 3 | Board Lock Mounting Brackets Shielded | C DC | 4 | Nickel Plated Steel | 62 | Board Edge Right Angle Through Hole | UL94 V-0 | 30 Áin | 0.76 Ám | 4-40 | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | White | Copper Alloy | Solder | Receptacle Female Sockets | D-Sub High Density | 8.89 mm | 0.35 in | 5 A | Signal | 4-40 | Gold | 3 | Board Lock Mounting Brackets Shielded | C DC | 4 | 62 | Board Edge Right Angle Through Hole | UL94 V-0 | 15 µin | 0.38 µm | |||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | Flash | Solder | Receptacle Female Sockets | D-Sub High Density | 8.89 mm | 0.35 in | 5 A | Signal | Housing/Shell | Gold | 3 | Mounting Brackets Shielded | C DC | 4 | Nickel Plated Steel | 62 | Board Edge Right Angle Through Hole | UL94 V-0 | 4-40 |
