T38313 Series
Manufacturer: Curtis Industries
Beta
⌘K
CONN BARRIER STRP 17CIRC 0.375"
| Part | Terminal Screw Material | Material Flammability Rating | Mounting Type | Operating Temperature | Material - Insulation | Bottom Termination | Current Rating (Amps) | Barrier Type | Wire Gauge [Max] | Wire Gauge [Min] | Number of Rows | Voltage Rating | Number of Wire Entries | Top Termination | Terminal Block Type | Pitch | Pitch | Number of Circuits | Number of Wire Entries [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Curtis Industries | Stainless Steel | UL94 V-0 | Chassis Panel Through Hole | 105 C | Polypropylene (PP) | Insulated PC Pin | 20 A | 2 Wall (Dual) | 22 AWG | 12 AWG | 1 | 300 VDC | 17 | Screws | Barrier Block | 9.53 mm | 0.375 in | 17 | |
Curtis Industries | Stainless Steel | UL94 V-0 | Chassis Panel Through Hole | 105 C | Polypropylene (PP) | Insulated PC Pin | 20 A | 2 Wall (Dual) | 22 AWG | 12 AWG | 1 | 300 VDC | 20 | Screws | Barrier Block | 9.53 mm | 0.375 in | 20 | |
 Curtis Industries | Stainless Steel | UL94 V-0 | Chassis Panel Through Hole | 105 C | Polypropylene (PP) | Insulated PC Pin | 20 A | 2 Wall (Dual) | 22 AWG | 12 AWG | 1 | 300 VDC | 14 | Screws | Barrier Block | 9.53 mm | 0.375 in | 14 | |
Curtis Industries | Stainless Steel | UL94 V-0 | Chassis Panel Through Hole | 105 C | Polypropylene (PP) | Insulated PC Pin | 20 A | 2 Wall (Dual) | 22 AWG | 12 AWG | 1 | 300 VDC | 2 | Screws | Barrier Block | 9.53 mm | 0.375 in | 2 | |
Curtis Industries | Stainless Steel | UL94 V-0 | Chassis Panel Through Hole | 105 C | Polypropylene (PP) | Insulated PC Pin | 20 A | 2 Wall (Dual) | 22 AWG | 12 AWG | 1 | 300 VDC | 6 | Screws | Barrier Block | 9.53 mm | 0.375 in | 6 | |
Curtis Industries | Stainless Steel | UL94 V-0 | Chassis Panel Through Hole | 105 C | Polypropylene (PP) | Insulated PC Pin | 20 A | 2 Wall (Dual) | 22 AWG | 12 AWG | 1 | 300 VDC | 1 | Screws | Barrier Block | 1 | |||
Curtis Industries | Stainless Steel | UL94 V-0 | Chassis Panel Through Hole | 105 C | Polypropylene (PP) | Insulated PC Pin | 20 A | 2 Wall (Dual) | 22 AWG | 12 AWG | 1 | 300 VDC | 10 | Screws | Barrier Block | 9.53 mm | 0.375 in | 10 | |
Curtis Industries | Stainless Steel | UL94 V-0 | Chassis Panel Through Hole | 105 C | Polypropylene (PP) | Insulated PC Pin | 20 A | 2 Wall (Dual) | 22 AWG | 12 AWG | 1 | 300 VDC | 15 | Screws | Barrier Block | 9.53 mm | 0.375 in | 15 | |
Curtis Industries | Stainless Steel | UL94 V-0 | Chassis Panel Through Hole | 105 C | Polypropylene (PP) | Insulated PC Pin | 20 A | 2 Wall (Dual) | 22 AWG | 12 AWG | 1 | 300 VDC | Screws | Barrier Block | 9.53 mm | 0.375 in | 7 | 7 |
