S802TS Series

Sen SCR 800V 1.5A 100 µA SOT223

Manufacturer: Littelfuse/Commercial Vehicle Products

Catalog

Sen SCR 800V 1.5A 100 µA SOT223

Part	Current - Non Rep. Surge 50, 60Hz (Itsm)	Current - Hold (Ih) (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Current - Gate Trigger (Igt) (Max) [Max]	Current - Off State (Max) [Max]	Package / Case	SCR Type	Voltage - Off State	Supplier Device Package	Mounting Type	Voltage - On State (Vtm) (Max) [Max]	Current - On State (It (RMS)) (Max)	Voltage - Gate Trigger (Vgt) (Max) [Max]	Current - On State (It (AV)) (Max) [Max]
Littelfuse/Commercial Vehicle Products S802TSRP	20 A 24 A	3 mA	-40 °C	125 ¯C	100 µA	3 µA	TO-261-4 TO-261AA	Sensitive Gate	800 V	SOT-223	Surface Mount	1.8 V	1.5 A	800 mV	900 mA

Catalog

Sen SCR 800V 1.5A 100 µA SOT223

Key Features

• RoHS compliant

• Glass-passivated junctions

• Voltage capability up to 800 V

• Surge capability up to 20 A

Description

The S802ECS offers a high static dv/dt with a low turn off (tq) time. It is specifically designed for GFCI (Ground Fault Circuit Interrupter) and AFCI (Arc Fault Circuit Interrupter), RCD (Residual Current Device) and RCBO (Residual Current Circuit Breaker with Overload Protection) applications. All SCR junctions are glass-passivated to ensure long term reliability and parametric stability.
