325-005 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 5POS 0.100
| Part | Termination Rows | Material - Insulation | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Card Thickness | Card Thickness | Contact Type | Contact Material | Read Out | Number of Positions | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Termination | Mounting Type | Number of Positions/Bay/Row | Gender | Flange Feature | Color | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | Cantilever | Copper Alloy | Single | 5 | Gold | -65 ░C | 125 °C | Non Specified - Single Edge | Solder | Through Hole | 5 | Female | Flush Mount M3 Threaded Insert Top Opening | Green | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | Cantilever | Copper Alloy | Single | 5 | Gold | -65 ░C | 125 °C | Non Specified - Single Edge | Solder Eyelet(s) | Through Hole | 5 | Female | 4-40 Flush Mount Threaded Insert Top Opening | Green | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | Cantilever | Copper Alloy | Single | 5 | Gold | -65 ░C | 125 °C | Non Specified - Single Edge | Wire Wrap | Through Hole | 5 | Female | Flush Mount Top Opening Unthreaded | Green | 0.16 " | 4.06 mm |
EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | Cantilever | Copper Alloy | Single | 5 | Gold | -65 ░C | 125 °C | Non Specified - Single Edge | Solder | Through Hole | 5 | Female | 4-40 Flush Mount Threaded Insert Top Opening | Green | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | Cantilever | Copper Alloy | Single | 5 | Gold | -65 ░C | 125 °C | Non Specified - Single Edge | Solder Eyelet(s) | Through Hole | 5 | Female | Green | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | Cantilever | Copper Alloy | Single | 5 | Gold | -65 ░C | 125 °C | Non Specified - Single Edge | Solder Eyelet(s) | Through Hole | 5 | Female | Flush Mount M3 Threaded Insert Top Opening | Green | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | Cantilever | Copper Alloy | Single | 5 | Gold | -65 ░C | 125 °C | Non Specified - Single Edge | Wire Wrap | Through Hole | 5 | Female | Flush Mount M3 Threaded Insert Top Opening | Green |
