G800MJ3 Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
PIN HEADER 2.54MM PITCH STR SMT,
| Part | Contact Finish Thickness - Post | Features | Insulation Material | Insulation Color | Connector Type | Number of Positions Loaded | Current Rating (Amps) | Operating Temperature [Max] | Operating Temperature [Min] | Material Flammability Rating | Fastening Type | Contact Finish - Post | Contact Type | Number of Positions | Contact Length - Mating | Contact Length - Mating | Contact Material | Contact Shape | Contact Finish - Mating | Mounting Type | Number of Rows | Shrouding | Contact Finish Thickness - Mating | Insulation Height | Insulation Height | Pitch - Mating | Pitch - Mating | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | Flash | Pick and Place | Nylon 6T Polyamide (PA6T) | Black | Header | All | 3 A | 105 ░C | -25 °C | UL94 V-0 | Push-Pull | Gold | Male Pin | 6 | 6 mm | 0.236 in | Brass | Square | Gold | Surface Mount | 1 | Unshrouded | Flash | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | Solder |
