R46KN Series

Manufacturer: KEMET

Catalog

CAP FILM SUPPRESSION X2 0.47UF 560VDC/275VAC PP 10%( 26.5 X 6 X 15MM) RADIAL PLASTIC RECTANGULAR CAN 22.5MM 110°C BAG

Part	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Lead Spacing	Lead Spacing	Operating Temperature [Min]	Operating Temperature [Max]	Capacitance	Voltage Rating - DC	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Voltage Rating - AC	Applications	Ratings	Package / Case	Termination	Tolerance	Mounting Type	Dielectric Material	Height - Seated (Max)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]
KEMET R46KN347000P1K	1.043 in	0.236 "	26.5 mm	6 mm	0.886 in	22.5 mm	-40 C	110 °C	0.47 µF	560 V	0.594 in	15.1 mm	275 V	EMI RFI Suppression	X2	Radial	PC Pins	10 %	Through Hole	Polypropylene (PP) Metallized
KEMET R46KN347045N0M	1.043 in	0.276 in	26.5 mm	7 mm	0.886 in	22.5 mm	-40 C	110 °C	0.47 µF	560 V			275 V	EMI RFI Suppression	X2	Radial	PC Pins	20 %	Through Hole	Polypropylene (PP) Metallized	16.1 mm	0.634 "
KEMET R46KN347050N0K	1.043 in	0.276 in	26.5 mm	7 mm	0.886 in	22.5 mm	-40 C	110 °C	0.47 µF	560 V			275 V	EMI RFI Suppression	X2	Radial	PC Pins	10 %	Through Hole	Polypropylene (PP) Metallized	16.1 mm	0.634 "
KEMET R46KN333045N0M	1.043 in	0.236 "	26.5 mm	6 mm	0.886 in	22.5 mm	-40 C	110 °C	0.33 µF	560 V	0.594 in	15.1 mm	275 V	EMI RFI Suppression	X2	Radial	PC Pins	20 %	Through Hole	Polypropylene (PP) Metallized
KEMET R46KN422040P0M	1.043 in	0.512 "	26.5 mm	13 mm	0.886 in	22.5 mm	-40 C	110 °C	2.2 µF	560 V	0.87 in	22.1 mm	275 V	EMI RFI Suppression	X2	Radial	PC Pins	20 %	Through Hole	Polypropylene (PP) Metallized
KEMET R46KN3330GYM1K	1.043 in	0.236 "	26.5 mm	6 mm	0.886 in	22.5 mm	-40 C	110 °C	0.33 µF	560 V	0.594 in	15.1 mm	275 V	EMI RFI Suppression	X2	Radial	PC Pins	10 %	Through Hole	Polypropylene (PP) Metallized
KEMET R46KN322000H1U	1.043 in	0.236 "	26.5 mm	6 mm	0.886 in	22.5 mm	-40 C	125 °C	0.22 µF	560 V	0.594 in	15.1 mm	275 V	EMI RFI Suppression	X2	Radial	PC Pins		Through Hole	Polypropylene (PP) Metallized
KEMET R46KN368050M2K	1.043 in	0.394 in	26.5 mm	10 mm	0.886 in	22.5 mm	-40 C	110 °C	0.68 µF	560 V		0.732 in	275 V	EMI RFI Suppression	X2	Radial	PC Pins	10 %	Through Hole	Polypropylene (PP) Metallized			18.6 mm
KEMET R46KN347040N0M	1.043 in	0.276 in	26.5 mm	7 mm	0.886 in	22.5 mm	-40 C	110 °C	0.47 µF	560 V			275 V	EMI RFI Suppression	X2	Radial	PC Pins	20 %	Through Hole	Polypropylene (PP) Metallized	16.1 mm	0.634 "
KEMET R46KN415000P0M	1.043 in	0.433 in	26.5 mm	11 mm	0.886 in	22.5 mm	-40 C	110 °C	1500 nF	560 V			275 V	EMI RFI Suppression	X2	Radial	PC Pins	20 %	Through Hole	Polypropylene (PP) Metallized
