0430310003 Series
Manufacturer: Molex
Beta
⌘K
8" PRE-CRIMP A2016L BLUE
| Part | Wire Gauge | Color | Number of Conductors | Contact Finish | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Length | Length | Contact End | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 22 AWG | Blue | 1 | Gold | 1 | 0.76 Ám | 30 Áin | 203.2 mm | 8 in | Pin to Cable (Round) | ||
 Molex | 24 AWG | Brown | 1 | Gold | 1 | 0.76 Ám | 30 Áin | 203.2 mm | 8 in | |||
 Molex | 22 AWG | Violet | 1 | Gold | 1 | 0.76 Ám | 30 Áin | 5 in | 127 mm | |||
 Molex | 24 AWG | 1 | Gold | 1 | 0.76 Ám | 30 Áin | 152.4 mm | 6 in | Pin to Cable (Round) | |||
 Molex | 20 AWG | White | 1 | Gold | 1 | 0.76 Ám | 30 Áin | 76.2 mm | 3 in | |||
 Molex | 24 AWG | Brown | 1 | Gold | 1 | 0.76 Ám | 30 Áin | Pin to Cable (Round) | 4 " | 101.6 mm | ||
Molex | 22 AWG | 1 | Gold | 1 | 0.76 Ám | 30 Áin | 76.2 mm | Pin to Cable (Round) | 3 in | |||
 Molex | 24 AWG | Red | 1 | Gold | 1 | 0.76 Ám | 30 Áin | 254 mm | Pin to Cable (Round) | 10 in | ||
Molex | 22 AWG | Brown | 1 | Gold | 1 | 0.76 Ám | 30 Áin | 76.2 mm | Pin to Cable (Round) | 3 in | ||
 Molex | 20 AWG | 1 | Gold | 1 | 0.76 Ám | 30 Áin |
