TMC2300 Series

Catalog

LOW VOLTAGE SILENT STEPPER MOTOR DRIVER 2…11V, UP TO 1.2A WITH ZERO STANDBY CURRENT 256 ΜSTEPS, COOLSTEP, STALLGUARD2 AND STEALTHCHOP

Part	Voltage - Load [Max]	Voltage - Load [Min]	Output Configuration	Current - Output	Voltage - Supply [Min]	Voltage - Supply [Max]	Supplier Device Package	Step Resolution [Min]	Step Resolution [Max]	Mounting Type	Function	Package / Case	Interface	Technology	Motor Type - AC, DC	Applications	Operating Temperature [Min]	Operating Temperature [Max]	Motor Type - Stepper	Supplied Contents	Primary Attributes	Type	Utilized IC / Part	Contents	Embedded	Secondary Attributes
Analog Devices Inc./Maxim Integrated TMC2300-LA	11 V	2 V	Half Bridge (2) Half Bridge (4)	1.2 A	2 V	11 V	20-QFN (3x3)	1	0.00390625	Surface Mount	Driver - Fully Integrated Control and Power Stage	20-VFQFN Exposed Pad	Step/Direction UART	Power MOSFET	Brushed DC	Automation Control Medical Printer	-40 C	125 °C	Bipolar
Analog Devices Inc./Maxim Integrated TMC2300-THERMO-BOB																				Board(s)	Motors (Stepper)	Power Management	TMC2300	Board(s)
Analog Devices Inc./Maxim Integrated TMC2300-BOB																				Board(s)	Motors (Stepper)	Power Management	TMC2300	Board(s)
Analog Devices Inc./Maxim Integrated TMC2300-EVAL-KIT																				Board(s)	Motors (Stepper)	Power Management	TMC2300	Board(s)	32-Bit MCU
Analog Devices Inc./Maxim Integrated TMC2300-MOTOR-EVAL																				Board(s)	Motors (Stepper)	Power Management	TMC2300	Board(s)		Graphical User Interface (GUI)
Analog Devices Inc./Maxim Integrated TMC2300-LA-T	1.95 V	1.65 V	Step/Direction	1.2 A	2 V	11 V	20-QFN (3x3)	1	0.00390625	Surface Mount	Driver - Fully Integrated Control and Power Stage	20-VFQFN Exposed Pad	Step/Direction UART	Power MOSFET		Automation Control Industrial Medical	-40 C	125 °C
