DG201 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

IC ANALOG SWITCH

Part	Switch Time (Ton, Toff) (Max) [custom]	Switch Time (Ton, Toff) (Max) [custom]	Current - Leakage (IS(off)) (Max)	Voltage - Supply, Single (V+) [Max]	Voltage - Supply, Single (V+) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Supply, Dual (V±) [Max]	Voltage - Supply, Dual (V±) [Min]	Multiplexer/Demultiplexer Circuit	Supplier Device Package	Mounting Type	Channel Capacitance (CS(off), CD(off)) [custom]	Channel Capacitance (CS(off), CD(off)) [custom]	On-State Resistance (Max) [Max]	Charge Injection	Package / Case	Package / Case	Package / Case	Number of Circuits	Switch Circuit	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case [x]	Package / Case [y]
Analog Devices Inc./Maxim Integrated DG201ABK
Analog Devices Inc./Maxim Integrated DG201ABJ	450 ns	600 ns	5 nA	18 V	4.5 V	85 C	-25 °C	18 V	-4.5 V	1:1	16-PDIP	Through Hole	5 pF	5 pF	200 Ohm	20 pC	0.3 in	16-DIP	7.62 mm	4	SPST - NC - Closed
Analog Devices Inc./Maxim Integrated DG201AAK/883B	450 ns	600 ns	1 nA					18 V	-4.5 V	1:1	16-CDIP	Through Hole	5 pF	5 pF	175 Ohm	20 pC		16-CDIP		4	SPST - NC	125 °C	-55 °C	0.3 in 7.62 mm
Analog Devices Inc./Maxim Integrated DG201AESER30129
Analog Devices Inc./Maxim Integrated DG201ADY+T	450 ns	600 ns	5 nA			85 °C	-40 °C	18 V	-4.5 V	1:1	16-SOIC	Surface Mount	5 pF	5 pF	200 Ohm	20 pC		16-SOIC		4	SPST - NC				0.154 in	3.9 mm
Analog Devices Inc./Maxim Integrated DG201ADJ+	450 ns	600 ns	5 nA			85 °C	-40 °C	18 V	-4.5 V	1:1	16-PDIP	Through Hole	5 pF	5 pF	200 Ohm	20 pC	0.3 in	16-DIP	7.62 mm	4	SPST - NC
Analog Devices Inc./Maxim Integrated DG201AESE+
Analog Devices Inc./Maxim Integrated DG201AC/D
Analog Devices Inc./Maxim Integrated DG201AMSE/PR	450 ns	600 ns	1 nA			85 °C	-40 °C	18 V	-4.5 V	1:1			5 pF	5 pF	200 Ohm	20 pC				4	SPST - NC
Analog Devices Inc./Maxim Integrated DG201AESE.G002
