895-019 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 19POS 0.100
| Part | Termination Rows | Material - Insulation | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Color | Mounting Type | Number of Positions/Bay/Row | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Card Type | Number of Rows | Termination | Read Out | Gender | Pitch | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 19 | 125 °C | -40 C | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Right Angle Through Hole | 19 | Copper Alloy | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | 1 | Solder | Single | Female | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 19 | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Through Hole | 19 | Copper Alloy | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | 1 | Wire Wrap | Single | Female | 0.1 " | 2.54 mm | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 19 | 125 °C | -40 C | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Right Angle Through Hole | 19 | Copper Alloy | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | 1 | Solder | Single | Female | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 19 | 125 °C | -40 C | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Through Hole | 19 | Copper Alloy | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | 1 | Wire Wrap | Single | Female | 0.1 " | 2.54 mm | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 19 | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Through Hole | 19 | Copper Alloy | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | 1 | Wire Wrap | Single | Female | 0.1 " | 2.54 mm | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 19 | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Through Hole | 19 | Copper Alloy | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | 1 | Wire Wrap | Single | Female | 0.1 " | 2.54 mm | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 19 | 125 °C | -40 C | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Through Hole | 19 | Copper Alloy | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | 1 | Wire Wrap | Single | Female | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 19 | 125 °C | -40 C | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Through Hole | 19 | Copper Alloy | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | 1 | Wire Wrap | Single | Female | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 19 | 125 °C | -40 C | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Through Hole | 19 | Copper Alloy | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | 1 | Wire Wrap | Single | Female | 0.1 " | 2.54 mm | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 19 | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Through Hole | 19 | Copper Alloy | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | 1 | Wire Wrap | Single | Female | 0.1 " | 2.54 mm |
